piezoelectric d33 meter

The Model YE2730 d33 meter is a special instrument for directly measuring the piezoelectric constant d33 values of piezoelectric ceramics, polymers, and single crystals.

This meter can also measure the d33 values in various single crystal directions for crystals such as lithium niobate, quartz, and tourmaline. This meter is capable for measuring the d33 value over a very large range, at high resolution, and with a high degree of reliability. The measurement is quick, and easily made with a minimum of training required. Specimens of a variety of sizes and shapes can easily be accommodated and measured. For example, the d33 value of disks, blocks, rings, tubes and semispherical shells can be easily measured on the Model YE2730 d33 meter. The direct d33 value readout is displayed on a 3 1/2 inch digital meter. This instrument is invaluable as a tool for quality assurance of piezoelectric materials, production in-line inspection, or for research applications.

        1. Three wires cable with connectors 1 piece

      2. Seven wires cable with connectors 1 piece

      3. Power cord 1 piece

      4. Core shape Probe head 2 pieces

      5. Plate shape probe head 2 pieces

      6. Standard test sample 1 piece

      7. Fuse 1 piece

      8. Operating manual1 piece

Our company was founded in 2001. We are the largest manufacture of vibration sensor and dynamic & static testing system in China. We are also the few one in high and new technology enterprises. We have the piezoelectric ceramic materials with the sensitive function,includes the test ,research ,development and production of its related components.

Our products are divided into four categories,which includes sixteen series. They are sensors, instruments,piezoelectric ceramic and flat fan. The amount of our products is more than three hundred.

We can offer you the products in good quality,good price and best service.
