AC DC Inverter TIG Welding Machines with Pulse TIG315P ACDC

Product details
Model Number:TIG 315P ACDC TIG machine;Pulse Frequency:0.5-300Hz ACDC TIG machine;
Dimensions:74 x 42 x 73cm ACDC TIG machine;Arc Current:15-315A ACDC TIG machine;
Brand Name:OEM ACDC TIG machine;Postflow Time:1-10s ACDC TIG machine;
Warranty:1 Year;Arc Force:0-100A ACDC TIG machine;
Payment Terms:L/C,T/T;Packaging Detail:1PC ACDC TIG machine TIG315P ACDC in a Carton with pollystyrene insert, carton size is 74 x 42 x 73cm;
Port:Shanghai Or Ningbo;Motor Type:AD/DC;
Pilot Arc Current:0-100A ACDC TIG machine;Duty Cycle:60% ACDC TIG machine;
Base Current:10-90% ACDC TIG machine;Power(W):5.8KVA;
Delivery Detail:45days for ACDC TIG machine TIG315P ACDC;Arc-starting:HF ACDC TIG machine;
Supply Ability:1000 Set/Sets per Month;Voltage:220V;
Place of Origin:Zhejiang China;Clean Width:10-90% ACDC TIG machine;
Condition:New;Power Supply:Three Phase AC220/380V±15% ACDC TIG machine;
Usage:ACDC TIG machine;Certification:CE;
After-sales Service Provided:Engineers available to service machinery overseas;No-load Voltage:70V ACDC TIG machine;
Pulse Frequency:0.5-300Hz ACDC TIG machine;Rated Duty Cycle:60% ACDC TIG machine;
Output Current Range:15-315A ACDC TIG machine;

Features for ACDC TIG machine TIG315P ACDC :



1. Advanced inverter technology, reliable quality, stable performance

2. Wide scope of power supply applicable.

3. Stable welding arc, less spattering, deep penetration, beautiful shape, high welding efficiency

4. Light weight, easy to operation

5. Remote control mode

6. AC/DC function, can be aluminium TIG welding with AC function.

7. Switching frequency is beyond audiorange, which almost eliminates noise pollution.

8. Self-adaptive are-force mode greatly improves the welding performance in long cable welding, and distant welding can be used



ItemUnitTIG315P AC/DCTIG315P AC/DC
(IGBT)(IGBT)
Power SupplyVThree PhaseThree Phase
AC220±15%AC380±15%
Input Power   FrequencyHz50/6050/60
Input Power   CapacityKVA8.816.9
Output Current   RangeA15-31515-315
No-load   VoltageV7070
Duty Cycle%6060
Arc-starting-HFHF
Postflow Times1-101-10
Clean Width%10-9010-90
Base Current%10-9010-90
Pulse   FrequencyHz0.5-3000.5-300
Downslope Times0-100-10
Arc ForceA0-1000-100
Efficiency%8585
Power FactorcosΦ0.930.93
Protection   Class-IP21SIP21S
Insulation   Class-FF
Weightkgs4949
Dimension of   Packingcm74 x 42 x 7374 x 42 x 73
