Shantui official road equipment SRP90S PLUS 9m width slip-form concrete paver

Product details
Engine Brand:DEUTZ;Dimension(L*W*H):7800*9000*3800mm;
Port:Qingdao,Tianjin,Shanghai;Place of Origin:Shandong China;
UNIQUE SELLING POINT:High operating efficiency;Brand Name:Shantui;
Applicable Industries:Construction works ;Product name:Shantui official SRP90S PLUS 9m width slip-form concrete paver;
Supply Ability:5000 Unit/Units per Year;Max. Paving Thickness:350mm;
Payment Terms:L/C,T/T,Western Union,MoneyGram;After-sales Service Provided:Video technical support,Online support,Field maintenance and repair service;
Power(W):159kw;Warranty:1 year;
Condition:New;Weight:24.4ton;

Shantui official SRP90S PLUS 9m width slip-form concrete paver



Multifunctional paver is a professional equipment used in asphalt concrete surface and base stabilized material paving of highway and other types of road. It is driven by hydraulic force and controlled by microcomputer; screed plate adopts double vibrating and eccentric vibratory compaction technology; material level adopts ultrasonic sensing control technology. This makes the paver have advantage of good paving stability, even material separating and feeding, high prepressing density, smooth surface and easy to operate. Therefore the S RP90S PLUS paver is an ideal construction machine for base and surface paving projects and it offers superior paving performance to maximize productivity while providing exceptional reliability.



More Types



Parameter

MODEL:SRP90S plusSRP95M plus
Base Paving Width (m)3-5.72.5
Maximum Paving Width (m)99.5
Maximum Paving Thickness (mm)350350
Paving Speed (m/min)0-180-18
Travel Speed (km/h)0-2.40-2.4
Hopper Capacity (t)1515
Theoretical Productivity (th)850850
Camber Adjustment(%) -1 - +3 -1 - +3
Climbing Ability (%)2020
Vertical Flatness (mm/3m)<2<2
Horizontal Slope Error (%)±0.020.02
Density Distribution Error (%)<5<5
Heating MethodGas heatingGas heating
Lubrication MethodCentralized Lubrication
Diesel EngineDeutz BF6M1013EC

BF6M1013EC/

Shangchai SC8D190G2B1

Power 0utput148148/140
RPM23002300
ScreedAVS9030DDVM9525Q
Vibration Speed (r/min)0-14700-1470
Vibration Distance (mm)43 ,5,7.9
Secondary Vibration Distance (mm)-0,3,6,9,12 .
Vibration Frequency (Hz)0-500-50
Machine Weight (t)2422
Maximum Operating Weight (t)2930
External Dimensions LxWxH(mm)7800x9000x38007300x9500x3800
Transport Dimensions LxWxH(mm)7800x3000x33607300x3000x3360
Technical Features

 Power system

Deutz BF6M1013EC turbocharger diesel engines feature the reliability, durability, long service life, strong power, low fuel consumption, compact structure and low maintenance fee.

Running system

The independent left and right running systems controlled with a micro-computer have the sound stability at low speed and the straight-line traveling performance. The wide track shoes and the sufficient ground length could provide the enough traction force under all severe conditions, guaranteeing the speed stability. The four-wheel and one-belt from the domestic famous brands could ensure the equipment reliability.

Screed

SRP95 pavers have two kinds of screeds: SRP95M being of mechanical extended type and SRP95S being of hydraulic – telescoping type, featuring sound working quality and high working efficiency.

Cab

The control system is able to move leftward, rightward, upward and downward. The two seats could rotate outwards. The auto lubricating device for the whole vehicle is easy and reliable, improving the stability. The ceiling could extend leftwards and rightwards, widening the operational field of view.

Safety, environmental-protection and energy-efficiency

Dalian Deutz engines feature the advanced technologies, reliability, low noise and emission, compliance with the stage-II emission standard, energy-saving and environmental – protection. In addition, the intelligent distributive technologies for power could greatly improve the working efficiency.





Working Conditions

This machine is suitable for paving the all roads, the asphalt concrete surface and the basic stable material, ideal to roadbed and road surface.



Packaging & Shipping



After-sale Service



Six Free Services

Free technical enquiries with our experts.
Free repair service during warranty period.
Free special services for all key construction projects.
Free 0 hour service upon deliver of machine.
Free training of operators and repairs staff.
Free maintenance service tracking (customer to provide resources)



Product and Technical Inquiries

We have established a team of specialists, knowledgeable in our products and services, in order to provide information and answers to our customers on technical issues.

Special Services for Key Projects

If Shantui machinery is in operation in key projects on a provincial level or higher, the customer will receive special services from Shantui (free special coating service, on-site service, extended on-site service). These special services will allow customers to work more freely without any worries.
