High quality 20kwh battery
- 1700.00 unit
| Size: | 490x353x353; | Voltage: | 2v; |
| Weight: | 125kg; | Product name: | 2V2000Ah battery; |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,Paypal; | Usage: | Signal system , emergency lighting system ,tools; |
| Port: | Shanghai or Ningbo; | Supply Ability: | 2000 Unit/Units per Week; |
| Packaging Detail: | carton box , wooden box and wooden pallet , 1unit per carton box; | OEM Order: | Acceptable; |
| Brand Name: | Yangtze; | Sealed Type: | Sealed; |
| Certification: | ce,ISO; | Terminal: | Cooper; |
| Certificate: | CE / ISO9001 / ISO14001 / Rohs; | Warranty: | 24 Months; |
| Model Number: | GFM-2000; | Battery type: | lead acid battery; |
| Place of Origin: | Jiangsu China; | Electrolyte: | Sulfuric Acid Thixotropic; |
| Maintenance Type: | Free; | Application: | Signal system , emergency lighting system ,tools; |
High quality 20kwh battery
Key Features :
♦Long service life according to EUROBAT Classification
♦Up to 2000 deep discharge cycles
♦High gas recombination efficiency
♦Wide suitability of ambient temperature range
♦Low self discharge
Applications :
♦Solar and wind energy storage system
♦EPS and UPS battery backup
♦Signal system , emergency lighting system , security system
♦Telecommunication Equipment
♦Power plant and transmission system
| 1. Functional Parameter | 5. Environment Temperature | ||
| Nominal Voltage | 2V | Discharge Temperature | -20~50℃ |
| Nominal Capacity (10 hour rate) | 2000Ah | Charge Temperature | -10~50℃ |
| Number of Cells | 2cells | Storage Temperature | -20~60℃ |
| 2. Rated Capacity at 25℃ (77° F) | 6. Inner Resistance & Max . Discharge Current | ||
| 10 hour rate (0.1C, 1.80V/cell) | 2000Ah | Fully Charged battery at 25℃ (77° F) | 0.22mΩ |
| 3 hour rate (0.25C, 1.75V/cell) | 1476Ah | Max. Discharge Current | 2000A (5s) |
| 1 hour rate (0.55C, 1.60V/cell) | 1016Ah | Short Circuit Current | 6800A |
| 3. Capacity affected by Temperature (10 hour rate) | 7. Self-discharge at 25℃ (77° F) | ||
| 40℃ (104° F) | 102% | Capacity after 3 month storage | 92% |
| 25℃ (77° F) | 100% | Capacity after 6 month storage | 84% |
| 0℃ (32° F) | 90% | Capacity after 9 month storage | 74% |
| -15℃ (5° F) | 70% | Capacity after 12 month storage | 65% |
| 4. Dimension and Weight | 8. Constant voltage charging at 25℃ (77° F) | ||
| Length | 490mm | Cyclic use | 2.35~2.4V |
| Width | 353mm | Maximum charging current | 500A |
| Height | 353mm | Temperature compensation | -5mV/℃ |
| Total Height | 353mm | Float use | 2.23~2.27V |
| Reference Weight | 125kg | Temperature compensation | -3.3mV/℃ |
♦ Battery factory Founded in 1996 , 2 million batteries annual production capacity
♦ Products including valve regulated lead acid battery , Gel battery , deep cycle battery , OPzV and OPzS battery
♦ Products are exported to more than 150 countries
♦ Products are certified by CE , UL ,Rohs
♦ Mature and very well respected AGM and GEL technologies for valve-regulated lead-acid batteries ranging from 2Ah to 3000Ah
