Low Price W12 series Automatic CNC Four-roller Hydraulic Plate Rolling Machine

Supplier: Jiangsu Longsheng Machine Manufacturing Co., Ltd.
Region: Jiangsu, China
Contact: Ms Lucy chen
Price: $13000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Year:	2018;	Automation:	Automatic;
Package Type:	Plastic film(usually) Wooden packaging(customized);	Max. Working Length (mm):	1500;
Motor Power (kw):	5.5;	Selling Units:	Single item;
After-sales Service Provided:	Engineers available to service machinery overseas;	Voltage:	220V/380V/415V/440V/customized;
Warranty:	24 Months;	Material / Metal Processed:	Aluminum,Carbon Steel,Brass / Copper,Stainless Steel,Stainless Steel/Carbon Steel/Aluminum;
Brand Name:	Longsheng;	Certification:	ce;
Electric parts:	SIEMENS;	Warranty:	2 Years;
Application:	Sheet Metal Bending/Rolling;	Condition:	New;
Single gross weight:	4,000 KG;	Key Selling Points:	High Productivity;
Package Preview:	https://sc01.alicdn.com/kf/HTB1uK7uXU_rK1Rjy0Fcq6zEvVXa6.jpg_640x640.jpg,https://sc01.alicdn.com/kf/HTB1J17uXU_rK1Rjy0Fcq6zEvVXaV.jpg_640x640.jpg;	Extra Services:	End Forming;
Hydraulic System:	YUKEN Japan;	Place of Origin:	Jiangsu China;
Machine Type:	Roller-Bending Machine;	Min Rolling Diameter:	300mm;
Single package size:	3000X1300X2400 cm;	No. of Roller:	4;
Applicable Industries:	Building Material Shops,Manufacturing Plant,Machinery Repair Shops,Construction works ,Energy & Mining;	Color:	White and Gray;
After-sales Service Provided:	Free spare parts,Field installation, commissioning and training,Field maintenance and repair service,Online support,Video technical support;	Rolling Speed (m/min):	4-6;
Weight:	3 tons;	Max. Plate Thickness (mm):	6;
Name:	Rolling Machine;	Raw Material:	Steel sheet;

Product Description

W12-series CNC Four-roller bending machine with international advanced technology, controlled by PLC programmable numerically, all hydraulic driving, it's a heavy duty CNC rolling machine which can come true automatic bending, also it's the nesy equipment for bending multi section curved, square, round, conical and other special shape working piece. With our four roller plate bending machine,plate can be bent on both side without return. The flat edge is 1.5-2 times of the thickness.

Model	W12-6X1500
Name	Four-roller plate rolling machine
Machine Type:	Hydraulic
Roller Material:	42CrMo
positioning Accuracy:	≤0.1mm
Controller:	Siemens
Valve:	Yuken from Japan
Feature:	High precision, high efficiency, Other
Decoration:	Sequins
Color:	Can be customized
Voltage:	Can be customized
Side Support:	Optional

Company Profile

Founded in 2005, Longsheng commits to the research and development of sheet metal machinery, pursuing the best quality and performance.
Now Longsheng has grown into one of the biggest manufacturers in the sheet metal processing equipment field. Our factory has a considerable scale -covers an area of 42,000 ㎡, with more than 200 employees, also owns an outstanding research and development department including 20 technicals and engineers.
The number of our main products has multiplied. It includes NC/CNC hydraulic rolling machine, mechanical rolling machine, 3-roller plate rolling machine, 4-roller plate rolling machine and so on. Moreover, various tooling and spare parts are also supplied as clients' demands.
