hengsheng digital high resolution visualizer 3d camera scanner

Click here to contact

Product details

Resolution:	VGA, SXGA(HDM);	Frame Rate:	30fps/s;
Packaging Detail:	Double polyfoam inside with double carton export carton with bundle strip;	Port:	Shanghai,Ningbo,Shenzhen;
Model Number:	HS-7500D;	Payment Terms:	L/C,T/T,Western Union;
pixel:	5 Mega;	Place of Origin:	Zhejiang China;
Interface type:	VGA, VIDEO, AUDIO, USB, SD card;	certificate:	CE, FCC ,ISO9000, ROHS;
Supply Ability:	10000 Set/Sets per Month OEM offered;	color:	black;
Zoom:	22*optical Zoom;	purpose:	education or conference;
Brand Name:	HS;

hengsheng digital high resolution visualizer 3d camera scanner

5.0 mega portable handy document scanner

Product Description

Category		HS-7500D
Optical	CMOS Size	1/3’’ professional CMOS
	Total Pixels	5000000 pixel
	SD card & U disk	YES
	HDM(I)	Option
	Line Resolution	1200 TVL
	Camera Head Rotation	340
	Frame Rate	24 (fps)
	Shooting Area	330×250mm max, 28 x 21mm min.
	Signal Noise Ratio(S/N)	50 dB
	Lens(mm)	F=1.6-3.8.f=3.9-85.8mm
	Powered Zoom	22×Optical(*)/ 10× digital
	Focus	Auto/Manual
	Iris	Auto
Lighting	Overhead Lamp	3W*2 LED(100000 lamp hours)
Lighting	Lower Lamp	Built in LED lighting box(1W)(100000 Lamp hours)
Imaging	Brightness Adjustment	Auto/Manual
	Video Signal	PAL/NTSC color system
	Resolution	SXGA (12801024)/XGA (1024768)
	Colour/B&W Selection	Yes
	White Balance	Auto/Manual
	Auto Image Adjust	Yes
	Text/Graphics Enhancement	Yes
	Image Zoom	Yes
	Image Freeze	Yes
	Image Rotation	340°(up/down)340°(left/right)
	Image Rotation	(including 90° and 180° degree)
	SHAPNESS Adjustment	Yes
	Colour (RED-BLUE)Adjustment	Yes
	Negative/Positive	Yes
	SCREEN DIV2	Yes
Terminals	VGA Input	VGA(DB15 FLC) ×1
	VGA Output	VGA(DB15 FLC) ×1
	VGA Output Resolution	SXGA (12801024)/XGA (1024768)
	RGB Output	1 pc
	Video/Audio input	Audio;3.5Mini jack×2, Video :RCA×1
	Video/Audio output	C-Video;RCA jack×1, Audio Mini jack ×1
	RS-232 connector	1 pc
	Power	12V/2A DC adapter, 30W
	Temperature	-10°C--50°C
	Folded Dimensions(WDH)	320x410x135mm
	Setup Dimensions(WDH)	320x410x490mm
	Dimensions(WDH)	515X440X250MM
	container (stack limit 8pcs )	495PCS/20" GP; 1035PCS/40'GP
	N.W./G.M.	3.5KGS/ 6KGS
	Accessories	User's Manual, VGA Cable, DC adapter
