EPA Approved China Mini Steer Skid Steer Loader Skid Steer Mini Track Skid Steer Loader

Click here to contact

Product details

Video outbound inspection:	if	type:	skid steer loader
Working weight:	890 kg	Skip tipping angle:	30°
Bucket capacity:	200kg	Machine weight:	800kg
Ground clearance:	105mm	Engine brand:	other
port:	Qingdao	Hydraulic valve brand:	other
Warranty:	2 years	Health status:	new
Unique Selling Points:	EPA engine	Hydraulic cylinder brand:	other
Workload:	200kg	Supply capacity:	1,000 sets per month
Showroom location:	Canada, UK, US, Italy, France, Germany, Spain, None	brand:	in front
Warranty:	2 years	Dimensions (lengthwidthheight):	203516951175mm
Noise (decibel):	≤95	strength:	15.4kW
Core components:	Engines, motors, pumps	Applicable industries:	Building materials stores, machine repair shops, farms, construction engineering, energy and mining
Mechanical test report:	if	Part Name:	Small skid steer loader for construction machinery
YFL380 mobile type:	Track loader	speed:	0-5.5km/h
Hydraulic pump brand:	other	payment terms:	L/C, Western Union, D/P, D/A, T/T, MoneyGram
Core component warranty:	2 years	Movement type:	Wheel loaders
aspect:	203516951175mm	Marketing type:	2020 new products
Place of origin:	Shandong Province, China

Welcome to Shandong Infront Machinery Co., Ltd.!

Practical value home!

thing	Using Chevron engineering tires
Maximum working height H1	2143 mm	84.37 inches
Maximum unloading height H2	1488mm	58.58 inches
Overall height H	1233mm	48.54 inches
Maximum pin height	1884mm	74.17 inches
Foot length	678mm	26.7 inches (foot pedal level)
Total length L including bucket (mm)	2206 mm	86.9 inches
Discharging distance at the highest point L1 (mm)	348 mm	13.7 inches
Excluding bucket length L2 (mm)	1752 mm	69 inches
Bucket width B (mm)	980 mm	38.6 inches
Total width B1(mm)	1160 mm	45.67 inches
Wheelbase	940mm	37 inches
Ground clearance (mm)	118mm	4.65 inches
Turning radius R (mm)	1307mm	51.5 inches
Bucket dumping angle α(°)	30
Bucket ground rollback β(°)	25
Departure angle (°)	11 (foot pedal level)

Technical Parameters:

Product YF380		thing
engine	Rated power(KW)	15.4KW (21 horsepower)
	Rated speed (rpm)	3300
Noise (decibel)		95
Hydraulic system	Hydraulic (Mpa)	number 17
	Cycle Time	Increase	dump	reduce
		4.27	1.34	3.31
Technical Parameters	workload	200kg	441 pounds
	Bucket capacity	0.15 meters³	5.33 (feet³)
	Maximum lifting force	375 kg	827 pounds
	Driving speed	0-5.5km/h	0-3.4 mph
	working weight	890kg	1958 pounds (with Chevron OTR tires)
tire		18*6.5-8
