4wd 40hp tractor with front end loader and shovel

Click here to contact

Product details

Health status:	new	product name:	4wd 40hp tractor with front loader and backhoe
model:	TZ-4	Origin:	Shandong China
maximum. Unloading angle:	47°	Bucket width:	1500mm
Certification:	International Organization for Standardization	Dimensions (LWH):	2206mm1160mm1233mm
brand:	champion	Packaging Details:	Iron frame packaging
type:	front loader	Bucket weight:	400 kg
Match with tractor power:	30-45 horsepower	Moving type:	Wheel loaders
Bucket capacity:	0.23 cubic meters	Supply capacity:	1000 sets per month
Quick Attachments:	Forks, haymakers, etc.	color:	red, black or any other
maximum. Scraping Depth:	140mm	port:	Qingdao Port
After-sales service provided:	Provide overseas third-party support	Warranty:	12 months
maximum. Dump height:	2000mm	specified load:	800 kg

Product Description

Introduction of 4wd 40hp tractor with front loader and backhoe:

1.TZ series tractor front loader can be installed on the tractor
Ranging from 25 to 120HP.

2. TZ series tractor front loaders can be used for farmland loading, unloading and transportation.

3. TZ series tractor front loaders can be used for garden grass/bale catching and snow removal.

4.TZ series tractor front loader can be used in forestry
Load wood.

4wd 40hp tractor with front loader and backhoe Specifications:

Main technical parameters of TZ series tractor front loader
loader model	TZ-3	TZ-4	TZ-8	TZ-10	TZ-12
Dimensions (mm):	4100×1600×1580	4100×1600×1580	4900×1739×2494	4900×1739×2494	5350×1800×3000
Power (HP):	20-30	30-45 years old	50-70	80-90	100-125
maximum. Discharge height(mm):	1800	2000	2200	2400	2800
maximum. Dumping distance(mm):	900	900	960	1000	1100
Bucket rollback angle (degrees):	42°	42°	42°	42°	42°
maximum. Unloading angle (degrees):	47°	47°	46°	46°	46°
maximum. Scraping depth(mm):	100	140	160	160	160
Time to lift to pivot pin (S):	7	7	8	8	10
Fall time (S):	3.5	3.5	4	4	10
Bucket width(m):	1.35	1.5	1.8	2	2.2
Bucket capacity (cubic meter):	0.2	0.23	0.43	0.6	0.65
