Internet phone caller ID USB interface, customer information management

Product details
color:whitePackage preview:
channel:singleAPI language:VB, VC, VF, C#, etc.
Packaging details:97*104*40mm/175gmodel:AD102
interface:USBFree development support:Yes
Place of origin:Guangdong, Chinatype:USB
Sales unit:Single productGross weight of single piece:0.120kg
Single piece packaging size:9X4X3cmbrand:Create together

This is a device required by all stores, including ordering pizza, snacks, and water, as long as the customer orders by phone


Main features:

- Record of incoming/outgoing call numbers, time and date

- Session duration count

- Compatible with ETSI/Bellcore FSK and DTMF caller ID

-Real-time line operating status indication

-Flexible system parameter programming

-HID USB data transfer, no USB driver required

-Multi-system LED indicator status control

-Provides a variety of speaking start conditions

-Can be expanded to 4 devices simultaneously

-Start call interval and missed call time settings

-Provides polarity reversal detection


Product specifications:

System Requirements:
Pentium 400 MHz CPU or above
Windows98se/XP/2000/NT operating system
10MB HD space or above

Standard USB port
Standard RJ11 interface

USB Audio Features:
Support USB2.0 full speed
Supports USB Audio Device Class Specification 1.0
Support Microsoft Windows98se/ME/2000/XP

Environmental requirements:
Operating temperature 0oC - 50oC (32oF - 122oF)
Storage temperature -30oC - 65oC (-22oF - 149oF)
Operating humidity 10% - 90% non-condensing

Product: Single-wire USB caller ID interface
Item number: AD101
Dimensions: 138 (length) × 106 (width) × 25 (height) (mm)
USB cable: 1.5M
Weight: 187 grams
Contents: AD101 hardware, SDK (AIP) and DEMO driver - CD, USB cable, RJ11 cable, user manual
