KEYENCE GT2-H12 GT2-H12F GT2-H12KF GT2-H12KLF Contact Distance Sensors Head Amplifier Unit Connector Type PNP New and Original

Click here to contact

Product details

Packaging details:	carton	Model:	GT2-H12
Supply capacity:	10 boxes per week	port:	Shenzhen
payment terms:	L/C, Western Union, D/P, D/A, T/T, MoneyGram	Minimum order quantity:	1
Package:	carton	Warranty:	1 year
series:	GT2-H	theory:	Contact distance sensor
Place of origin:	Japan	brand:	Keyence
Installation type:	Fixed installation	feature:	Contact distance sensor
model:	GT2-H12	type:	distance sensor
describe:	contact distance sensor,contact distance sensor	usage:	Contact distance sensor

detailed picture

Product Description

Model				GT2-H12
Detection Systems				Proportional shooting system, absolute (no tracking error) type
Measuring range				12mm
solve				0.5 micron
Indication accuracy				2 microns (pp)*1
force measurement	Install downward		1.0 cattle*2
		Side installation		0.9 cattle*2
		Install upward		0.8 cattle*2
The sampling period				1 millisecond
mechanical response				10 Hz*1
Running lights				2 color LED (red, green)
Environmental resistance	Enclosure rating		IP67 (International Electrotechnical Commission)
		ambient temperature		-10 to +55 °C (no freezing)
		Relative humidity		35 to 85 % RH (non-condensing)
		Vibration resistance		10 to 55 Hz, dual amplitude 1.5 mm, 2 hours each in X, Y, and Z directions
		Impact resistance		1,000 m/s2 (IEC60068-2-27)
Material	main body		Body shell: die-cast zinc, indicator: polyarylate (PAR)
		dust cover		Nitrile rubber
		touch		SUS304, SUS440C*3
Sensor head cable				Optional (connects to M8 connector)
weight				About. 95 grams (excluding cable)
1 Values when the ambient temperature is 20 °C. 2 Representative value at the center of the measurement range. Please note that measuring force varies depending on installation Condition of dust jacket. *3 Contacts are available as an option sold separately.
