New quality good quality cheap wholesale intelligent permanent magnet frequency conversion constant pressure booster pump Products from Shenzhen Nanmiao South Technology Co., Ltd.

Product Details

pressure:	other	Rated head:	18M
Customization support:	OEM production	Motor Power:	350w
Single package size:	34X26.5X21.5 cm	Origin:	Zhejiang, China
Voltage:	220V 50HZ	Inner diameter size:	DN25
application:	Domestic housing, drinking water treatment, irrigation and agriculture	model:	PBG4-30
Maximum flow:	4.5 cubic meters per hour	size:	305210275mm
engine:	Permanent Magnet Synchronous Motor	structure:	single stage pump
feature:	LCD touch screen	Gross weight per piece:	5.000 kg
Limited Data:	2.4 cubic meters per hour	engine:	Permanent Magnet Synchronous Motor
Energy source:	electrical	Sales unit:	single product

Product overview

permanent magnet motor

A permanent magnet motor is an electric motor that uses, in addition to windings for its field, permanent magnets instead of just windings.

List of functions

The electric pump can work continuously and normally under the following conditions: 1. Medium temperature 0~+60℃; 2. Ambient temperature 0~+40℃; 3. The pH value of the culture medium is between 6.5 and 8.5; 4. Solids in the medium The volume ratio of impurities does not exceed 0.1%, and the particle size is not large at 0.2mm; 5. The power frequency is 50Hz, the rated voltage is single-phase 220V, and the voltage must not be lower than 160V.

product specification

No	thing	data
1	Model	PBG4-30
2	strength	350W
3	Maximum head	30 meters
4	Voltage	220V 50/60HZ
5	Internal dimensions	DN25
6	take the lead	18 meters
7	Limited Data	2.4 cubic meters per hour
8	Maximum flow	4.5 cubic meters per hour
