7-Ton Trolley Accumulator Locomotive for Mining

7-Ton Trolley Accumulator Locomotive for Mining

What are the advantages of using frequency conversion speed regulation for 7-ton trolley electric locomotives?

There are many ways to adjust the speed of the 7-ton trolley locomotive, each with its own advantages and disadvantages. This article mainly introduces the advantages of using frequency conversion speed regulation for 7-ton trolley electric locomotives.

First of all, both frequency conversion speed regulation and chopper speed regulation are stepless speed regulation, while resistance speed regulation is based on gears. Moreover, the controllability and safety of the frequency conversion speed regulation have been greatly improved, which makes the start of the trolley locomotive more stable.

In addition, unlike resistance speed regulation and chopper speed regulation, there is no requirement. Frequency conversion speed regulation is based on the use of AC motors in trolley locomotives. DC motors use direct current, without frequency, frequency conversion is out of the question. Therefore, the advantages of AC motors over DC motors are also part of the advantages of using frequency conversion speed regulation for 7-ton trolley locomotives. For example, the structure of AC motors is simpler and more reliable, the probability of failure is smaller, and it is easier to maintain and so on.

Moreover, the 7-ton trolley locomotive forms a complete circuit with the overhead line, the return track, and the substation. When regenerative braking is used, the regenerative current can be returned to the grid to save energy.

The above are the main advantages of using frequency conversion speed regulation for 7-ton trolley electric locomotives.

7 ton trolley wire locomotive	Adhesive / total weight (t)	7 ton
	Track gauge (mm)	600.762.900
	Traction (KN)	13.05 15.09
	Max. Traction (KN)	17.2
	Speed(km/h)	11
	Power (KW)	21X2  24X2
	Dimensions Length(mm)	4550
	Width(mm)	1050,1212or 1350
	Height(mm)	1600
	Wheelbase (mm)	1100
	Wheel diameter (mm)	680
	Min Curve radius (m)	7
	Controller	Resistencia or IGBT
	Braking method	Mechanical

Advantages of our product

1.Using high-quality steel plates, special rust removal process make sure it more anti-corrosion and suitable for harsh mining environment.
2. Producing motors ourselves, using high lever insulation material and pure copper, ensure the powerful traction force, and suitable for harsh mining environment.
3.Gear anastomosis surface to reach more than 80%, which is far more exceeding the standard.
4.Professionally designed and adjusted frame ensure safe driving and avoids falling off rails.
5.A variety of braking methods can be choose, air brake, hydraulic brake, electric brake, mechanical brake to ensure the safety drive.
6. 40 years richful experience with the ability to design and make customized product according to your requirements.
7. Proving factory online-visiting

Mining Locomotive test
1.Before Running the locomotive,carry out gear debugging, lighting, gear, and brake adjustment etc.To ensure the normal operation of the locomotive.
2.Carry out a tensile test before leaving the factory to ensure the load performance of the locomotive meets the standard. Our design standards generally exceed the national standard by 10%-20%.
3.Carry out different type running test before leaving the factory to ensure the performance and normal operation of the whole locomotive. It can adapt to various harsh conditions under simulated working conditions.

Motor test
The motor has to go through many inspection procedures before leaving the factory, and each motor has to be carried out with load running experiments.
Explosion-proof motors are carried out with water pressure test.
All the test of motor is to ensure that can adapt to harsh working conditions.

1. A good feedback of our lithium battery locomotive from a client of Latin America
2. In order to solve the exist problems of lead-acid batteries. More than 30 lead-acid battery electric locomotives in this large mining were changed into lithium battery electric locomotives, which improved the work enthusiasm and production efficiency of employees, reduced costs,and more environment-friendly.
3. The mining rock drill car designed by Sunward Co., has a small size and simple structure, so the space for placing the lithium battery on the body is very limited.
According to the limitation size, our company design a lithium power supply power plan, which
perfectly solves the problem of lithium power supply space.
In order to adapt to the special industrial and mining environment and improve transportation efficiency, a batch of 2.5-ton lithium battery electric locomotives are designed to Myanmar Clients.
