Juice plastic popsicle tubes in different shapes

Click here to contact

Product details

Extruder motor power (kW):	7.5 kW	Screw aspect ratio:	25
color:	choose	Voltage:	380V
Mechanical test report:	if	Video shipment inspection:	if
Air pressure (MPa):	0.8 MPa	Die heating power (kW):	0.7 kW
Screw heating power (kW):	5.5 kW	Output (kg/h):	55 kg/h
Packaging Details:	wood	Power (kW):	16.25
application:	bottle	Marketing Type:	New Products 2020
Weight (ton):	0.72	Accumulator capacity (L):	25 liters
Warranty:	1 year	Health status:	new
Mold platen size (width) (mm):	350 mm	Core components:	PLC, bearings, gearboxes, motors
After-sales service provided:	Provide overseas service centers, on-site maintenance and repair services, on-site installation, commissioning and training, free spare parts, video technical support	automation:	automatic
Screw diameter (mm):	65 mm	Clamping force(kN):	2200
Power (watts):	16.25KW	Core component warranty:	1 year
weight:	720KG	Blow molding type:	extrusion blow molding
Dimensions (LWH):	280012001800MM	Certification:	CE certification
Mold platen size (height) (mm):	460mm	brand:	Yue Feng
After warranty service:	Video Technical Support, Spare Parts	automatic:	Yes
Showroom location:	not any	Applicable industries:	Machinery repair shop, manufacturing plant, food and beverage factory, food store, advertising agency, food and beverage store
Local service location:	not any	Supply capacity:	30 sets per month
port:	Tianjin harbor	Plastic processing:	PP, HDPE, polystyrene, PE, PE/PP, HDPE/PP
Air consumption(m³/min):	1.2 m3/min	Origin:	China
payment terms:	L/C, T/T, Western Union	Main selling points:	high security level

5l Hdpe Plastic Tank Container Extrusion Blow Mold/Blow Molding Machine

big blow molding machine

This model is our newly developed product, featuring high output and low power consumption.

Easy to maintain and easy to operate, it fills the blank of blow molding machines within 5L at home and abroad, and is cost-effective

Technical Parameters	cpj-1	cpj-2	cpj-3
equipment composition	6-station blow molding machine with 55 extruders	Four-station blow molding machine with 45 extruders	8-station blow molding machine with 65 extruders
Maximum product volume ml	1200	800	1500
Product diameter mm	100	80	110
Die size (lengthwidthheight) mm	120×118×300	120×118×300	120×118×300
Production capacity PCS/day	20000-120000	15000-80000	20000-160000
Air consumption m3/min	0.4	0.4	0.4
Screw diameter mm	55	45	65
Major Radius Ratio	25:1	25:1	25:1
Plasticizing capacity kg/h	40	25	60
Motor power kw	7.5	5.5	11
Total power kw	17	14	twenty two
weight kg	1800	1500	2000
Appearance size (lengthwidthheight) mm	3300×1200×1500	3000×1200×1500	3400×1300×1600
suitable raw material	PE/PP/PS/PVC	PE/PP/PS/PVC	PE/PP/PS/PVC
Speed regulation method	frequency conversion	frequency conversion	frequency conversion
