Hydrogenerator micro-hydrogenerator low water head 10kw 20kw micro-hydrogenerator hydroturbine

Supplier: Shenzhen Shengyouan Industry Co., Ltd.
Region: Guangdong, China
Contact: Mr Brady Zhang
Price: $750.00 /set
Min. Order: 1 set

Click here to contact

Product details

Warranty 10kw Hydro Generator:	1 year	Certification:	ce
place of origin; place of origin:	Guangdong, China	flow:	0.035 - 0.06(m3/s)
10kw water turbine generator use:	Hydraulic direct drive generator	Voltage:	220V-240V
strength:	3kw-10kw	Supply capacity:	10000 sets per month
Design Leader:	yes	Colorful 10kw hydroelectric generator:	green option
Phase 10kw water turbine generator:	single phase/three phase	Certificate 10kw hydro generator:	CE ISO9001
Warranty:	1 year	Material 10kw hydro generator:	copper
payment terms:	L/C, Western Union, D/P, D/A, T/T	Voltage 10kw water turbine generator:	220V/240/380/415V options
port:	Shenzhen Port	frequency:	50 Hz
model:	4	rated power:	3kw-10kw
brand:	SUA	Packaging Details:	Plywood Packed Hydro Generator
custom made:	yes	Name 10kw hydro generator:	hydroelectric generator

Product Description

Turgo turbine generators are suitable for water heads above 8m and flows above 0.003m3/s. The main features are:

1. The integration of steam turbine and generator makes installation and maintenance more convenient

2. The hydraulic direct-drive generator does not need more driving mechanisms, with higher efficiency and extremely low failure rate.

3. The generator has a built-in self-stabilizer, and the voltage is more stable.

4. Optional single-phase voltage 220-240V or three-phase voltage 380V-415V. The generator's unique voltage excitation design is suitable for long-distance voltage transmission.

5. Mainly used for: sufficient water source in mountainous area, water head greater than 8 meters

Size Information

Model	Rated output	maximum output	Voltage/single phase/three phase	frequency	head/elevation	water flow
WG-3KW	3KW	3.3KW	220-240V / 380-415V	50Hz±5%	15M-30M	0.015 - 0.03(m3/s)
WG-5KW	5KW	5.5KW	220-240V / 380-415V	50Hz±5%	15M-40M	0.015 - 0.04(m3/s)
WG-8KW	8KW	8.8KW	220-240V / 380-415V	50Hz±5%	25M-55M	0.025 - 0.05(m3/s)
WG-10KW	10KW	11KW	220-240V / 380-415V	50Hz±5%	30M-60M	0.035 - 0.06(m3/s)

detailed image
