Direct Xingda soft frequency conversion starter cabinet fire pump fan control box panel

Supplier: Luoyang Bozhi Automatic Control Technology Co., Ltd.
Region: Henan, China
Contact: Ms lybozhi xu
Price: $200.00 / 1 - 49 pieces
$150.00 / >=50 pieces
Min. Order: 1 piece

Click here to contact

Product details

model:	Primus--Pump Control	place of origin; place of origin:	Henan, China
size:	custom made	Certificate:	CCC CE CB ISO9001
Installation type:	Wall-mounted	Warranty:	1 year
Supply capacity:	100 pieces per month	product name:	Switchboard water pump
Function:	Motor Start Panel	thickness:	0.8-1.5mm
port:	Shanghai	payment terms:	L/C, Western Union, D/P, D/A, T/T, MoneyGram
Packaging Details:	wooden box/iron box/carton	Material:	cold rolled steel
brand:	Hiroshi	MOQ:	1 set
Programmable Controllers:	Siemens or customized

Professional technical team one-stop service remote technical support

Product Description

The fire inspection cabinet can automatically inspect the fire water pump; in order to prevent the fire water pump from being idle for a long time, the rust will cause the water pump to fail to work normally; The water system is not pressurized, and there is no starting current, which prolongs the service life of equipment and equipment.

The fire inspection cabinet is divided into two parts: the main circuit inspection and the fire equipment non-pressure inspection, which can complete the low-frequency automatic inspection of the main control circuit and the water pump. The system is not pressurized during the inspection, and the intelligent inspection controller outputs control commands. Check the main circuit contactor in turn, check that the return signal is taken from the main and auxiliary contacts of the contactor, and the feedback signal does not exceed 2S. After the inspection of the main circuit is completed, the inspection controller sends the next inspection instruction to the non-voltage inspection device. After receiving the inspection instruction, the inspection device will conduct low-speed and no-pressure inspections on the fire pumps in sequence.

industrial application
