Joint Toothed 8M and 14M HTD Timing Pulleys

Available Tooth Profiles

Number of teeth

part

Available Aperture

Material

surface treatment

8M, 14M;

10~100

Can be equipped with threaded holes, screws, etc.

pilot hole

keyway

set screw

Cone hole

aluminum

brass,

steel,

cast iron

Aluminum anodized and black anodized or

Zinc phosphating or galvanizing of steel products

Hole precision

H7, H8

belt part

asphalt

outer diameter

(Pcd difference is small)

belt width

tooth depth

High torque drive pulleys with curved tooth geometry, i.e. as follows:

8M timing pulley

8.000 mm

1.37mm

20,30,50,85mm

3.560 mm

14M HTD timing pulley

14.000 mm

2.80mm

40,55,85,115,170 mm
