OPTIC TECH Low Price 20W Fiber Laser Marking Machine

Supplier: Optic Technology (Shenzhen) Co., Ltd.
Region: Guangdong, China
Contact: Mr OPTIC LASER
Price: $4000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Laser Type:	Fiber Laser;	Selling Units:	Single item;
Working Accuracy:	0.01mm;	Application:	Laser Marking;
Laser head:	Galvo head;	Laser Source Brand:	RAYCUS;
Laser wavelength:	1064nm;	Package Preview:	https://sc02.alicdn.com/kf/HLB1IKpxO4YaK1RjSZFnq6y80pXah.jpg_640x640.jpg;
Brand Name:	OPTIC;	Package size:	950x860x1540mm;
Cooling Mode:	Air Cooling;	Certification:	CE,ISO,SGS,FDA;
Delivery Detail:	0 days after payment;	Place of Origin:	Guangdong China (Mainland);
Control Software:	EZCAD;	Package Type:	Standard export wooden boxes;
Warranty:	3 years;	Laser safty:	Class 4;
G.W.:	155KG;	After-sales Service Provided:	Online support,Free spare parts,Video technical support;
Condition:	New;	Laser Head Brand:	Sino;
Applicable Industries:	Hotels,Garment Shops,Building Material Shops,Manufacturing Plant,Machinery Repair Shops,Food & Beverage Factory,Farms,Restaurant,Home Use,Retail,Food Shop,Printing Shops,Construction works ,Energy & Mining,Food & Beverage Shops,Advertising Company;	Control System Brand:	BJJCZ;
Graphic Format Supported:	AI,BMP,DST,DWG,DXF,DXP,LAS,PLT;	Single gross weight:	155 KG;
CNC or Not:	Yes;	Single package size:	88X80X140 cm;

Product Description

OPTIC TECH Low Price 20W Fiber Laser Marking Machine

The fiber Laser Marking Machines From OPTIC allow manufacturers to mark or engrave barcodes,serial numbers,2D Data Matix and graphics on the widest variety of materials including metals,plastics and ceramics and leave permanent marking.They provide an industrial solution for Product identification and traceability and are often chosen by customers because of the product's capabilities and quality,as well as the quality of mark it produces.

Machine Features

Marks widest variety of materials, including steel, titanium, aluminum, copper, ceramics & some plastics
100,000+ hours of laser life, reducing costs and production downtime
Small 19" rack mount footprint makes it easy to integrate with other equipment and existing assembly lines
110mm square mark field (other sizes available)
No consumables and minimal maintenance help reduce operating costs
Mount laser in any orientation
Air-cooled
Real-time visible live pointer for previewing your mark
Higher beam quality than flash lamp, diode pumped and vanadate, resulting in a high quality mark

Sample Mark Gallery

OPTIC is known for the high quality of the marks we produce, and these samples from OPTIC Fiber Lasers showcase some of the common applications that highlight its capabilities. Fiber lasers can be used for a wide variety of applications, from industrial traceability to branding, on materials such as steel, copper, aluminum, plastic, ceramic, and brass.

Watch videos of the Fiber Laser marking.
https://www.youtube.com/playlist?list=PL08RkhuE74l02m5zdaVG5IMdC006o8AsU

REQUEST SAMPLE MARKING

Don’t see what you’re looking for? To help you find the right marking equipment for your application, OPTIC offers free sample marking so that you can see what the mark would look like on your material.

We will afford a return shipping for each sample.

Configuration

Standard Configuration
Laser generator	Raycus fiber laser
Laser scanner	Sino
F-theta lens	Wavelength
Control board	BJJCZ
Software	EZCAD
Lifting pillar(48cm)	Manual
Computer	Industrial computer 4G 60G
Disply	19" display
Red pointer	Yes
2D working table	Yes
Safety Goggles	Yes
User Manual	Yes
Optional
Rotary device	50 or 80mm in diameter
Fume extractor	For collecting dust
Fixture	For fixing flat material

Parameters

MACHINE TECHNICAL SPECIFICATIONS

Catagory	Spec.
Laser type	Fiber,Ytterbium dopted
Output power	20W
Power requirement	220v/110V single ph,50-60HZ
Wavelegth	1064nm
Operation mode	Pulsed
Cooling	Fan Asisted Air Cooling
Scanning method	XY galvanometer
Approvals	CE FDA ISO
Warranty	3 years.
Documentation	User manual,Online video troubleshooting
Package Dimension	950x870x1540mm(37.4"x34.3"x60.6")
G.W	150kg(330 Ibs)

LENS CONFUGURATIONS

Lenses	Marking field	Focal length
70x70mm	70x70mm	100mm
100x100mm	100x100mm	165mm
175x175mm	175x175mm	254mm
200x200mm	200x200mm	310mm
300x300mm	300x300mm	419.8mm

FAQ

Q:Can it mark on metal,plastic or ceramic?

A:Yes and no.You can mark on metal,plastic ceramic but results are different.It have best result on metals and ABS PET PA PP ETC.We need test if you want to mark on plastic or ceramic.

Q:What's the lead time?

A:We just need 3 days for production and the lead time will within a week usually.But the lead time will be longer in busy season.Please contact with us before placing order.

Q:What's your warranty?

A:3 years warranty.We will repair to replace the parts for free.

Q:I'm worry about the payment.

A:We support trade assurance which make the payment easier and with safty.Please check the page----https://tradeassurance.alibaba.com/?spm=a272a.11111163.jc04ilky.17.1b5834d31oiet4&traclog=xbzx

Especially you can pay through Alibaba with your Credit card

Please contact with us if you want to pay by other method.

Q:What's the shipping method?What's the shipping time and cost?

A:We usually ship this size machine by sea.The shipping time will be different from 15 to 60 days depend on your position.The shipping cost is also depends on your position and time.Contact us for shipping cost and shipping time.
