Automatic computerized high speed 3 layer laminating machine film laminating machine

Automatic computerized high speed 3 layer laminating machine film laminating machine

It is for BOPP,PET,NYLON,CPP,CPE,Aluminium foil,paper etc roll form material two layer or multi layer laminated to be high strenth, high fresh keep and steam resistance etc good quality packing material.

1 overall machine adopt PLC tension control and protection to improve machine reliability

2 first and second unwinding, oven,rewindign part with closed loop constant temperature tension,it will be showed and controled by human interface.

3 six section pneumatic open constant temperature oven, air out and intake layering,pressure load design, two times air reback, it is not only save the energy , but also reduce remain solvent content.

4 oven inner guide roller adopt active and passive type, drive adopt synchronous belt wheel to avoid materail pulling and deformation.

5 the first and second unwinding (face film and liner) all adopt EPC air sensitive webguide, the film output of oven adopt EPC inclined webguide

6 hi precision gravure roller coating system, pneumatic doctor blade,uniform roller, glue cycle device.

7 high precition backpress three roller laminating device,laminating roller adopt out cycle oil heating device to make the heating more uniform.

8 coating, laminating machine unit adopt double frequency linkage drive and enter PLC control

9 by cooling roller to make the film more smooth and neat

10 rewinding by two AC vector motor control the taper tension, pneumatic back roller cutting knife and auto splicing to reduce waste
