Officially manufactured 400mm asphalt cold milling machine XM405/XM405S load construction equipment

Supplier: Cruking Engineering Equipment (Xiamen) Co., Ltd.
Region: Fujian, China
Contact: Ms Sheanifu Xie
Price: $37000.00 / 1 - 2 units
$30000.00 / >=3 units
Min. Order: 1 unit

Click here to contact

Product details

rated power:	470/2100 kW/rev	product name:	cold milling machine
Showroom location:	Philippines, India, Russia, Algeria, South Africa, Uzbekistan, Malaysia	Warranty:	1 year
place of origin; place of origin:	China	port:	Shanghai, Qingdao, Lianyungang
Certification:	CE/ISO	brand:	top brand
Applicable industries:	Clothing Stores, Building Materials Stores, Farms, Construction, Energy and Mining	Cooling Type:	water cooling
Milling width:	400 mm	Marketing Type:	New Products 2022
Milling depth:	120 mm	payment terms:	L/C,Western Union,D/P,T/T,MoneyGram
Core Components Warranty:	1 year	Supply capacity:	300 units per month
strength:	470 kW	application:	road construction work
maximum. Speed of work:	85 m/min	Unique Selling Points:	long lasting
Packaging Details:	bare package, container	Video external inspection:	if
Dimensions (LWH):	765025803000 mm	Mechanical test report:	if
Packaging Preview:		Ground clearance:	320 mm
Tool spacing:	15/18 meters	Health status:	new
feature:	fast delivery	Model:	XM405/XM405S
Core components:	PLC, engine, bearing, gearbox, motor, pressure vessel, gear, pump	Weight (kg):	34000

Officially manufactured 400mm asphalt cold milling machine XM405/XM405S load construction equipment

product description

Road Construction Machinery 400MM Asphalt Concrete Milling Machine

XM405Asphalt concrete milling machine is a maintenance and construction machine for asphalt concrete pavement.
The equipment has the characteristics of advanced performance, high efficiency, simple process, easy control of milling depth, flexible operation, good maneuverability, and recycling of old materials. It is an ideal equipment for road maintenance and renovation.

Performance and Features:
1. The hydraulic driven milling drum has the obvious features of smooth milling and high efficiency.
2. Compact three-wheeler, front-wheel drive.
3. High-strength, high-wear-resistant imported cutter head and cutter holder, long service life and low cost.
4. Imported hydraulic components are used, and the working reliability is high.
5. Hydraulic hand-held crusher and rumble bar equipment can be selected.

Product parameters

thing			unit	XM405
Maximum milling width			mm	400
Maximum milling depth			mm	120
Milling wheel	Tool spacing	mm	15/18
		Number of tools		42
		Milling wheel diameter (with tool)	mm	580
		Maximum inclination angle of milling wheel	°	5
Diesel engines	cooling method		water cooling
		Model		QSX15
		Number of cylinders		6
		rated power	kilowatt	470
		engine speed	number of revolutions	2100
		Fuel consumption: full load	l/h	125
Speed/Level Capability	Speed of work	m/min	0-85
		Walking speed	km/h	0-5
		Theoretical gradeability (working block)	%	80
		Ground clearance		320
Weight/Load	Shipping weight	Kilogram	30000
Weight/Load		working weight	Kilogram	34000
tracking device	front track	mm	1720×300×620
tracking device		rear track	mm	1720×300×620
Box volume	tank	large	1400
		Hydraulic tank	large	300
		water tank	large	3400
		electronic system	five	twenty four
Conveyor belt device	Aggregate conveyor belt width	mm	850
		Discharge conveyor width	mm	850
		Conveyor belt conveying capacity	≤m3/h	375
Shipping size	Mechanical (L×W×H)	mm	7650×2580×3000
Shipping size		Belt Conveyor (L×W×H)	mm	8060×1150×1500
