tire recycling production line rubber tire recycling

1. Double shaft shredder

Optima's two-shaft shredders are designed with aggressive low-speed, high-torque shredding technology. Each axle is driven by its own Siemens motor, giving it enough power to drive tires and thick steel balls. Shredder blade thicknesses range from 25mm to 152mm (1''-6"), depending on tire type, output and desired end product. Shredders can process OTR at speeds of up to 10 tons per hour Tires, truck tires and car tires.

2. Grater

The grater is the ultimate machine for midstream grinding and steel separation. It is specially designed to process pre-shredded tire chips and produce wire-free rubber coverings between 25-12mm (1" - 0.5"). The grater can handle up to 6 tons of input per hour. The main rotor housing is equipped with replaceable wear plates to increase the durability and longevity of the cutting chamber. Another unique feature of this machine is the ability to turn the tool once before sending it for sharpening or replacement, minimizing operating costs.

3. Granulator

The granulator is designed to grind the rubber covering in the grater into small particles as fine as 1 mm. The particles are screened and recycled until the desired size is achieved. Due to the design of the pelletizer and the precise alignment of the blades, the pelletizer produces a very uniform cut and high quality pellets. During the pelletizing process, 99% of the fibers are removed, leaving uncontaminated rubber crumb particles that can be further processed or sold.
