black oil refinery machine,black car oil distillation plant

Supplier: Chongqing Tong Rui Filtration Equipment Manufacturing Co., Ltd.
Region: Chongqing, China
Contact: Mr Kunlun Lee
Price: $30000.00 /set
Min. Order: 1 set

Click here to contact

Product details

certification:	ISO9001:2008,SGS,CE,BV;	Condition:	New;
Applicable Industries:	oil recycling;	Material:	Stainless steel and Carbon steel;
Place of Origin:	Chongqing China;	Showroom Location:	None;
Flow:	55-200 L/Min;	Warranty:	1 Year;
chemical cost:	30 USD/T;	Power:	38-285KW;
Brand Name:	TONGRUI;	environmental protection:	no waste gas; no waste water;
Weight:	7~15 TONS;	Packaging Detail:	Wooden Cases:To be packed in strong wooden cases, suitable for long distance ocean freight transportation as well as changing climate and with good resistance to moisture and shocks.;
Marketing Type:	New Product 2020;	Supply Ability:	4 Set/Sets per Month;
After-sales Service Provided:	Engineers available to service machinery overseas,Online support;	ultimate vacuum:	50 PA;
product quality:	light yellow; no foul smell;	size:	provide customise;
Noise:	75dB(A);	Port:	CHONGQING/SHANGHAI;
After Warranty Service:	Video technical support;	Video outgoing-inspection:	Not Available;
Dimension(LWH):	Custom-made;	Payment Terms:	L/C,T/T,Western Union,MoneyGram;
Machinery Test Report:	Not Available;	Warranty of core components:	1 Year;
Certification:	CE ISO;	Voltage:	220V/380V/240V,220~415V;
Core Components:	Engine,Pump;	Local Service Location:	None;

Newest technology with high oil output engine oil distillation plant

Working principle :

Waste oil is pumped to mix with the catalyst after being pretreated to remove large impurities, and mixed enough via the special mixing pipe. The mixed waste oil flows into the distillation kettle, meanwhile the waste oil is circulating heated by the heat exchanger. Start the vacuum unit. The components by distillation pass through three-stage cooling systems, then collected into "water receiver, gasoline and diesel receiver, light lube base oil receiver, heavy lube base oil receiver" . The waste gas is firstly handled by the water seal, then handled by our waste gas processor system. The water distilled from waste oil can be used to blend the catalyst, no any pollution water produced. The gasoline and diesel oil distilled from waste oil can be used as fuel blended with oil residue. Therefore, our equipment has no any secondary pollution to the environment.

Advantage:

Distillation is the physical separation of components of lubricating oil by boiling range. Depending on the type of distillation, the boiling ranges can produce gases and gasoline at the lower boiling points with heavy lubricating oils being distilled at higher boiling points. Distillation is the core process for a facility capable of producing re-refined base-oils to virgin base-oil quality.

It’s easy to produce waste residue and bad smelling by traditional vitriol distilling, which will bring potential secondary pollution, moreover, it’s easy to change the color to black and produce the odor due to the recycled oil react with the oxygen. But after we use the alkaline complex catalyst refines the oil, the recycled oil haven’t change the color and haven’t create the odor. What’s more important, you can use the residue to be as the fuel to heating the oil, without any pollution. And the machine is easy to operate; only 1-2 workers is enough to control the machine.

Features:

1. Easy to operate, low operation cost

2. Environmentally friendly, without secondary pollution.

3. The machine can recycle gasoline oil, diesel oil, engine oil, rubber oil and other lubricant oil to clean oil.

4. High quality refined oil, no any discoloration caused by oxidation, no any bad smelling.

5. Low cost contain:

1) only need the catalyst chemical, the cost is less thanUS$30 to refine one ton waste oil.

2) Heat consumption: 10⁵kcal per ton waste oil

3) Power consumption: 40Kwh to recycle 1 ton waste oil

6. High degree of automation.

Recovery Rate:

Component	Percentage(%)
water	1.5%
Gasoline/diesel oil	7%
Light Lubrication oil	42%
Heavy Lubrication oil	43%
Residue	6.5%
Total	100%

Treated Oil Analysis (take the waste diesel engine oil for example)

Item	Heavy Lube oil	Light Lube Oil
Appearance	lucidity	lucidity
Color ≤	1.5	1
Viscosity (40°C)mm2/s	49.57	26.86
Viscosity Index ≥	96	95
Anti-oxidation 150°C,min ≥	180	180
Deemulsification,54°C	5min	5min
Flash Point(Open)°C ≥	228	224
Pour Point °C ≤	-12	-16
neutralization value (mgKOH/g) ≤	0.02	0.02
