Product details
Min. IC Pitch:0.30mm;Min solder mask clearance:0.3mm;
Min. Line Width:0.075 mm;Solder mask type:Green/yellow/black/red/white;
Min. Line Spacing:0.075 mm;Base Material:FR4/CEM-4/Aluminum/SIC;
Impedance Control:+/-10%;Layers:1-32 layers;
certificate:ISO/ROHS;Profiling Punching:Routing, V-CUT, Chamber;
Surface Finishing:ENIG/Lead Free HASL;Electricity performance testing:100% electrical performance testing, high pressure testing;
Copper Thickness:0.5 oz ~ 7.0 oz;Board Thickness:0.35mm ~ 7.0mm;
Payment Terms:T/T,Western Union,paypal;Place of Origin:Guangdong China;
Model Number:FM20150807-26;Min solder mask thickness:0.01mm;
Brand Name:OEM/ODM;Supply Ability:300000 Piece/Pieces per Month Quickly;
Port:HK/Shenzhen;Min. Hole Size:0.1 mm;
Board Size:1-32Layers+;Packaging Detail:Anti-static Bubble Bag & Carton;

 PCB Manufacturer in China and High Quality PCB Board Manufacturer with PCB Assembly Service

Thanks for choosing Fumax

- Your Best Reliable Design & Manufacturing Partner in China!



 Fumax can provide excellent Turnkey project service for worldwide customers. Our factory has over 800 staff with a group of experienced mechanical & Electronic engineers. We are able to manufacture products starting from initial product design, Electronic Circuit Design, PCB Layout, Components Sourcing & Purchasing, Plastic / Metal mechanical design, Mold / Tooling design & fabrication, sub-assembly, full assebmly to final product testing / package.





Product Description

PCB Manufacturer in China and High Quality PCB Board Manufacturer with PCB Assembly Service

Products Application:

-Household appliance

-Medical products

-Automotive products

-Industrial products

-Consumer electronics



PCB Technical Capabilities:

Layer

1-32 layers

Material

FR4,CEM1,CEM3,Hight TG,FR4 Halogen Free,FR1,FR2,94v0

Order Quantity

1-500,000

Board shape

Rectangular,round,slots,cutouts,complex,irregular

Board type

Rigid,flexible,rigid-flexible

Board material

FR-4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc

Board cutting

Shear,V-score,tab-routed

Board thickness

0.2~4.0mm,Flex 0.01~0.25''

Copper weight

1.0,1.5,2.0oz

Solder mask

Double-sided green LPI,Also support red,white,yellow,blue,black

Silk screen

Double-sided or single-sided in white,yellow,black,or negative

Silk screen min line width

0.006'' or 0.15mm

Max board dimensions

20inch*20inch or 500mm*500mm

Min drill hole diameter

0.01'',0.25mm.or 10 mils

Surface finish

HASL,Nickle,Imm Gold(ENIG),Imm Tin,Imm Silver,OSP etc

Board thickness tolerance

± 10%

Copper weight tolerance

± 0.25oz

Minimal slot width

0.12'',3.0mm,or 120mils

V-score depth

20-25% of board thickness

Plated through holes

Yes

Sink holes

Yes

Design file format

Gerber RS-274X,274D,Eagle and AutoCAD'S DXF,DWG



PCB Assembly SMT & DIP manufacturing Capabilities:

+

Quantity

Prototype, Low, Medium, High Volume PCB Assembly,

Type of Assembly

SMT, Thru-hole, Cable assembly, Wire Harness

Min. IC Pitch

0.30mm

Foot Pin

SO, SOP, SOJ, TSOP, TSSOP, QFP, BGA and U-BGA

Min. Chip Placement

1005

Max. PCB Size

410 x 600mm

Min. PCB Thickness

0.35mm

Maximum BGA Size

74 x 74mm

BGA Ball Pitch

1mm ~ 3mm

BGA Ball Diameter

0.4mm ~ 1mm

QFP Lead Pitch

0.38mm ~ 2.54mm

Solder Type

Water Soluble Solder, Lead-Free, Wave soldering

Components

Passive Down to 0201 size



BGA and VFBGA



Leadless Chip Carriers/CSP/QFN



Double-sided SMT Assembly



Fine Pitch to 0.8mils



BGA Repair and Reball



Part Removal and Replacement

File Format

Bill of Materials



Gerber files



Pick-N-Place file

Types of Service

Turn-key, Partial turn-key or consignment, pilot run

Component packaging

Cut Tape, Tube ,Reels, Loose Parts

Turn Time

Same day service to 15 days service

Programing

Hex file or bin file firmware.

Testing

Flying Probe Test, X-ray Inspection AOI Test

Package

Anti-static Bubble Bag & Carton

PCB assembly process

IQC for incoming materials checking----Material baking----SMT----- Semi-Products Testing & QC ---DIP parts -- IPQC--- Wave Soldering--Semi-Products Testing & QC-----Assembling-----ICT or X-ray-----100% Function Testing-----Reliability Testing (burn-testing) - Package - Shipping



Finished Assembly:



+

Make you a finished product - Turnkey Project - Directly shipping to your customers!

Finished Assembly

PCB Assembly + Plastic Enclosure

+ Package

PCB Assembly + Metal Enclosure

+ Package

PCB Assebmly + Cable

+ Package

PCB Assebmly + Wire Harness

+ Package

PCB Assebmly + any combined or other enclosures

+ Package





Company Information

  Fumax - Your Best Reliable Design & Manufacturing Partner in China!



Our dedication to cutting-edge technology, product excellence, consistent quality, competitive pricing, unsurpassed service and customer satisfaction has brought us outstanding recognition in these industries.

Our OEM/ODM design team has the expertise to rapidly prototype upon the approval of finalized specifications. In addition, the winning of ISO-9001 certification ensures the exactitude of our research and development procedures with the highest product quality. For complete customer satisfaction, we also provide an extended product service and warranty program.



Our current products line included, but not limited to:

+

Consumer Electronics

Video player, Audio products, Cafe Machine

Industrial control

Motor Control board, Industrial Control, Machine Board…etc.

Wireless industry

Smart Card Readers, Wireless communication

Tele-communication

Communication Modules

Medical

electrocardiograph monitoring, Blood Press Meter

Plastic/Metals

Metal Emblems, Stapler, Calculators, Screw Driver, Hammer

And many other OEM/ODM products



Strong Sourcing &Supplier Chain Management:

Factory View:





Our Services

(1) Fumax employs a complete team of engineers from a variety of backgrounds :

  • Industry Designers
  • Electronic Engineers
  • Mechanical/Construction Engineers
  • Mold/Tool Engineers
  • Package Engineers

(2) OEM (We manufacture according to your design - BOM, Gerber file and testing procedures,  while providing you best recommendations for easy manufacturing and cost saving):

  • Component sourcing and procurement
  • PCB Manufacturing
  • Component Assembly (PCBA–SMT & Through Hole parts)

      Chip-on-board (COB)

      Surface-mount technology (SMT)

      Ball-grid array (BGA)

      Through-hole

  • Plastic Enclosure (Mould) Manufacturing
  • Metal Enclosure (Tool) Manufacturing
  • Cable  & Wire harness Assembly
  • Final Assembly
  • QC Testing
  • Packaging

(3) ODM (We design and manufacture for you):

  • New Product Design
  • PCB Layout
  • Reverse Engineering
  • Software Programming
