Hot Sale 15000L stainless steel drinking truck mounted water tank

Supplier: Hubei Huayi Special Automobile Co., Ltd.
Region: Hubei, China
Contact: Mr Robert Pang
Price: $9600.00 /unit
Min. Order: 1 unit

Click here to contact

Product details

Payment Terms:	L/C,T/T,Western Union,MoneyGram;	Chassis model:	Dongfeng;
Condition:	New;	Emission Standard:	Euro 3;
After-sales Service Provided:	Overseas third-party support available,Video technical support,Field installation, commissioning and training,Field maintenance and repair service,Free spare parts,Online support;	Showroom Location:	Viet Nam,Philippines,Peru,Indonesia,Pakistan,Thailand,Kenya,Chile,Algeria,Sri Lanka,Bangladesh,Nigeria;
Marketing Type:	New Product 2020;	Supply Ability:	300 Unit/Units per Month;
Warranty of core components:	1 Year;	Drive Wheel:	4X2;
After Warranty Service:	Spare parts,Field maintenance and repair service;	Applicable Industries:	Building Material Shops,Machinery Repair Shops,Farms,Construction works ;
Application:	Water Sprinkling;	Packaging Detail:	Nude;
Warranty:	1 Year;	Tank Volume:	10001 - 15001L;
Core Components:	Engine,Gearbox,Pump;	Sprinkling Area (m):	12 - 16m;
Engine Capacity:	4 - 6L;	Gross Vehicle Weight:	6815;
Place of Origin:	Hubei China;	Brand Name:	Dongfeng;
Transmission Type:	Manual;	Pump:	Chinese Famous Brand;
Color:	customized;	Tank material:	4mm Carbon Steel;
Local Service Location:	Viet Nam,Philippines,Peru,Indonesia,Pakistan,Mexico,Thailand,Malaysia,Kenya,Chile,UAE,Algeria,Sri Lanka,Bangladesh,South Africa,Kazakhstan,Kyrgyzstan,Nigeria,Uzbekistan,Tajikistan;	Video outgoing-inspection:	Provided;
Fuel:	Diesel;	Package Preview:	;
Dimensions (L x W x H) (mm):	8290x2370x2760mm;	Emissions standard:	Euro III;
Machinery Test Report:	Provided;	Wheelbase:	4700mm;
Port:	Any chinese port;	Engine:	CUMMINS;
Certification:	ISO9001;

Product Description

Vehicle parameters
Vehicle Model	EHY5160GSSD	Vehicle Brand	HUAYI
Overall dimensions	8500X2460X3000mm	Curb weight	6185kg
Tank dimensions	5200×2100×1445mm	Tank volume	12000L

Chassis parameters
Chassis model			DFL1160BX	Chassis brand	DONGFENG
Overall dimensions			8290x2370x2760mm	Wheel base	4700mm
Front/rear wheel track			1880/1800mm	Front/rear suspension	1430/2160mm
Approach/departure angle			20/13°	Maximum speed	90km/h
Chassis Manufacturer			Dongfeng Motor Company
Cab	Configuration		Tianjin a row and a half deluxe cab(with sleeping berth),,hydraulic mechanical flip,channel type instrument panel,air conditioner,allowable 3 passengers
	Color		white,other color is optional
Engine	Model		B190 33
	Emission		Euro 3
	Type		6 cylinders,in-line,4-stroke,water-cooled,turbo inter-cooling,diesel engine
	Rated power		190hp,rated power speed 2500rpm
	Displacement		5900ml
	Max.torque		640N·m
	Bore x stroke		102x120mm
	Manufacturer		Dongfeng Cummins Engine Co., Ltd.
Tire	Size		9.00-20 nylon tire
	Number		6+1 nos
Clutch	push type diaphragm spring clutch,Φ395mm
Frame	(250x80x[7+4])mm
Fuel tank	160L,steel
Front axle	3.6T
Rear axle	9.0T main reduction ratio 5.286
Drive form	4X2
Rated voltage	24V,DC
Transmissions	Gearbox DF6S750, 6 speed forward 1 reverse.
Steering device	Power assisted steering
Steering wheel	Left hand drive
Selective configuration		Steel wire tire
If there is a slight change in the chassis parameters above,please take the actual product as the standard

Water tank structure parameters
Tank dimensions		5200×2100×1445mm	Tank volume	12000L
Tank material		Carbon steel	Tank thickness	4/5mm
Nozzle sprinkling width		≥14m	Range of water cannon	≥28m
Suction height		≥7m	Color and Logo	Optional
Standard configuration	Chassis, sub frame, carbon steel water tank, manhole, water pump, front/side/rear spray nozzle,rear working platform,water cannon,fire valve, water valve, filter gauze,water hose, climbing ladder.
Selective configuration	Stainless steel/aluminum alloy water tank,insulation layer for water tank,stainless steel water pump, fire pump, fire gun,pesticide plate, cabin gas control operated, Honda pumps, lights, crane, hanging basket, rear spraying device, barrel pesticide spraying device, gasoline pesticide machine, diesel pesticide machine, LED arrow lights
Extended model	water transporting truck, thermal insulation water transporting truck, drinking water tank truck, liquid food truck, fire water tank truck, pesticide spraying truck,and etc.
