Factory Cheap Price Packing Machine Fully Automatic Box Cartoning Machine

Supplier: Shanghai Biaozan Industrial Co., Ltd.
Region: Shanghai, China
Contact: Ms BiaoZan Tao
Price: $15000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram,Paypal;	Packaging Detail:	Standard Wooden Case;
Driven Type:	Electric;	Application:	Food,Beverage,Commodity,Medical,Chemical,Machinery & Hardware;
Condition:	New;	Key Selling Points:	High Productivity;
Carton Size Range:	L(50-250)mmW(20-170)mmH(15-70)mm;	Machine Noise:	≤80dB;
Packaging Material:	Paper;	Showroom Location:	None;
Gas Source:	0.5-0.8Mpa;	Brand Name:	Biaozan;
Applicable Product:	Toothpaste, Soap, Cpsmetic, Bag, Bottle, etc.;	Instructions Size Range:	L(100-260)mm*W(100-190)mm;
Place of Origin:	Shanghai China;	Productivity:	40-60 pcs/min;
Local Service Location:	None;	Carton Paper Requirements:	250-450g/m3;
Manual Paper-Based Requirements:	55-70g/m3;	After Warranty Service:	Video technical support,Online support,Field maintenance and repair service;
Keyword:	Cartoning Machine;	Type:	Packaging Line;
Dimension(LWH):	350015001600mm;	After-sales Service Provided:	Online support,Video technical support,Field installation, commissioning and training,Field maintenance and repair service;
Warranty:	1 year;	Certification:	CE;
Automatic Grade:	Automatic;	Voltage:	220V/380V/50Hz/60Hz;
Applicable Industries:	Hotels,Food & Beverage Factory,Farms,Restaurant,Home Use,Retail,Food Shop,Food & Beverage Shops;	Weight:	1200KG;
Packaging Type:	Cartons,Boxes;	Supply Ability:	100 Set/Sets per Month Carton Packing Machine;
Port:	Shanghai, Shenzhen, etc.;	Air Consumption:	120-160L/min;

Factory Cheap Price Packing Machine Fully Automatic Box Cartoning Machine

Characteristics

HTZH-100 Automatic Cartoning Machine is intelligent, continuous automatic cartoning equipment, maximum speed up to 60 boxes/min. This machine is suitable for automatic feeding and packing of food, medicine, daily chemical, entertainment, hardware and other articles.The automatic feeding mechanism is easy to adjust, and the box loading speed can be arbitrarily set on the operation screen.The whole process of on-line material inspection, paper tongue packaging at both ends of the carton (also suitable for hot melt adhesive), missing material elimination and finished product output is completed automatically.

Cartoning Machine Technical Parameters:
Material Type	Number Reference
Box Speed	80-120 boxes/min
Carton Paper Requirements	300-400g/m2
Size Range	L: 40~260mm, W: 20~170mm, H: 15~70mm (LongWideHigh)
Compressed Air Pressure	0.6MPa
Air Consumption	20m³/h
Voltage	380V/220V-50Hz/60Hz
Main Motor Power	1.5KW
Machine Size	350013501800mm
Weight	1200KG
Box Size:
MIN (mm)	MAX (mm)
A (Wide) 20	170
B (High) 15	70
C (Long) 40	260
A+B	240
Box Requirement	≥300g/m2

Please don't be hesitate! Contact us and get more Cartoning Machine details!

Product Overviews

Click for More Information !!!

Applications

Click for More Information !!!

Packaging & Shipping

Click for More Information !!!

Company Information

Click for More Information !!!

Our Services

Our Advantages:

20 years’ experience in Packaging Machinery manufacturing.
15 years of experience in International trade, serving customers with more than 100 countries and regions.
Strong technical strength, can quickly resolve customer problems.
Also, OEM/ODM service are available.

After-Sales Service:

After sales service, our engineer is available to supply door to door service for our customers and also they will tell our customer how to operate the machine. And also all of our engineer is ready for the service of the customer for 24 hours per day. We have sufficient spare parts stock and can meet your needs in time.
