Frequency Counter SF-103 Ctcss Meter 2mhz-2800mh Wireless Signal Scanner With Ctccss/dcs Decoder

Supplier: 409 SHOP
Region: Hong Kong S.A.R., China
Contact: Mr Chan Wing Wah
Price: $30.00 / >=10 pieces
Min. Order: 10 pieces

Click here to contact

Product details

Brand:	SURECOM;	Battery build-in:	Li-ion 3.7V 600mah;
Frequency range A:	2MHz-200MHz;	Place of Origin:	Hong Kong S.A.R.;
Dimensions:	70 x 30 x 90mm;	Accuracy Class:	+-2.5ppm;
Type:	Frequency Counter Meter With Ctccss/dcs Decoder;	Measuring Range:	10MHz ~ 3Ghz;
Voltage:	5V;	Payment Terms:	T/T,Western Union,Paypal;
Port:	Hong Kong or Shenzhen;	Frequency range B:	27MHz -2800MHz;
impedance input:	50 Ohm;	current consumption:	30-50MA;
Supply Ability:	1000 Piece/Pieces per Week;	DIGITAL:	3-6;
Brand Name:	SURECOM;	Model Number:	SF-103;
Net Weight:	113g;	Measure distance:	0.3-9M;
Display Type:	Digital Only;	Packaging Detail:	each frequency counter packed with box 10pieces or above package with cartoon;
Operating Temperature:	-45 ℃ ~ 65 ℃;

New Frequency Meter SF-103 Ctcss Counter 2mhz-2800mh Radio Portable Frequency Counter Meter With Ctccss/dcs Decoder

Specifications:

SF-103 RF frequency counter

New Function: for analog and digital Radio

The SURECOM SF-103 hand-held frequency counter is a more practical counter, even advanced features such as field strength measurement are incorporated. It is compact, truly pocket sized, test instrument designed for ease of use and dependable performance. Supplied as a complete with internal Li-ion battery pack, AC wall charger and antenna.

Introduction:
- The frequency meter capable of measuring the parameters of the frequency of the continuous carrier signal walkie-talkies , with signal strength indicator.
  it is the tool of choice for maintenance personnel ,test frequency and signal strength for wireless enthusiasts.
- This portable frequency counter is designed for counting continuous wave signal comes from Two-way Radio.
- There are easy ranges for you to choose. The ranges cover most of the frequency of the two way radios you want to measure.
- Its four-button control is easy to use and its small size allows you to carry it anywhere you like.
- Work by TCXO(Temperature Compensate X'tal (crystal) Oscillator) ,In the range of -45 ℃ ~ 65 ℃ can reach ± 2 ~ ± 4ppm accuracy
- This include very interesting frequency areas such as 2m HAM radio, all VHF and UHF
- DMR Radio signal e frequency counter.
- GUI Battery level
Feature & Specification:
- Frequency range two select : 2MHz-200MHz / 27MHz -2800MHz
- CTCSS/DCS Decoder
- Frequency counter Digital mode for DMR radio
- Work by TCXO( Temperature Compensate X'tal (crystal) Oscillator) 2~2.5ppm
- Frequency Response time: 0.2-0.5sec.( CTCSS/CDCSS >0.5-1sec)
- TFT Color Display 240 x 320 ,LCD Dim level setting
- Build-in Li-ion battery
- Net Weight: 113g
- 4 buttons control
- Auto power off 1-9minutes
- Charging battery LED indicator

Package include:
1 x SF-103 frequency counter
1 x DUAL BAND UHF / VHF antenna
1 x BELT CLIP
1 x USB CHARGER with cable .
1 x ENGLISH MANUAL

Specifications for FREQUENCY

FUNCTION	SF-401-PLUS	SF-103
Frequency Range:	27MHz-3000MHz	2MHz-2800MHz
Gate Speeds select:	N/A	0.1 / 0.25 / 0.5 / 1.0 Second
DIGITAL:	3-4	3-6
DIGITAL mode :	DMR system
Distant :	0.3-1M	0.3-9M
Walkie talkie code of CTCSS/DCS:	must be 132-173 / 200-260MHz / 400-519MHz
Signal attenuation s.w.	-10db by switch	AUTO GAIN
Li-ion Battery Built-in:	600mAH	1500mAH
TFT LCD:	320 x 240 pixels
Current consumption:	10MA	30-50MA
TCXO crystal Oscillator	+- 2.5ppm	+- 2.5ppm
Charger input:	Micro USB +5V in
Impedance input:	50 Ohm (BNC)
Weight:	100g	113g
Dimensions size :	70 x 25 x 90mm ( not include antenna & BNC socket)

CTCSS/DCS Decoder for ANALOG mode

CTCSS (Hz)
50.0	97.4	151.4	192.8
55.0	100.0	156.7	196.6
67.0	103.5	159.8	199.5
69.3	107.2	162.2	203.5
71.9	110.9	165.5	206.5
74.4	114.8	167.9	210.7
77.0	118.8	171.3	218.1
79.7	123.0	173.8	225.7
82.5	127.3	177.3	229.1
85.4	131.8	179.9	233.6
88.5	136.5	183.5	241.8
91.5	141.3	186.2	250.3
94.8	146.2	189.9	254.1

CDCSS for ANALOG mode (N code only)

Standard(N)	sf401 check	Standard(N)	sf401 check	Standard(N)	sf401 check	Standard(N)	sf401 check
Standard(N)	sf401 check	Standard(N)	sf401 check	Standard(N)	sf401 check	Standard(N)	sf401 check
23	23	143	143		266	465	465
25	25		145	271	271	466	466
26	26	152	152		274	503	503
31	31	155	155	306	306	506	506
32	32	156	156	311	311	516	516
	36	162	162	315	315	532	532
43	43	165	165		325	546	546
47	47	172	172	331	331	565	565
51	51	174	174		332	606	606
	53	205	205	343	343	612	612
54	54		212	346	346	624	624
65	65	223	223	351	351	627	627
71	71		225		356	631	631
72	72	226	226	364	364	632	632
73	73	243	243	365	365	654	654
74	74	244	244	371	371	662	662
114	114	245	245	411	411	664	664
115	115		246	412	412	703	703
116	116	251	251	413	413	712	712
	122		252	423	423	723	723
125	125		255	431	431	731	731
131	131	261	261	432	432	732	732
132	132	263	263	445	445	734	734
134	134	265	265	464	464	743	743
						754	754

OPTIONAL : Tailor made Multi-language (MOQ in 50pieces)

English, French, German, Russian, Japanese, Chinese Traditional......

Model	Country (Market)	Language
SF-103	USA,UK,CANADA..	ENGLISH
Below Model for tailor made Multi-language
SF-103-C	CHINA	Simplified Chinese
SF-103-F	France	français
SF-103-H	HONGKONG, TAIWAN	Traditional Chinse
SF-103-I	India
SF-103-J	JAPAN	Janpese
SF-103-K	Korea
SF-103-M	Malaysia	Malay
SF-103-R	RUSSIAN FEDERATION
SF-103-S	Spain
SF-103-T	Thailand
