Glass cutting table L3020 CNC water jet cutting glass machine

3 axis waterjet cutting machine

A high pressure water jet cutting machine is a tool which slices into metal and other materials, using a jet of water at high velocity and pressure. Because of its advantages of low noise, no pollution, high precision and good reliability, it has been widely used in mining, automobile, paper-making, food, art, construction and other industries.Waterjet can cut almost every thing, including metal,glass,plexiglass,ceramic,marble, granite, rubber and compound material etc.

Dynamic 5axis water jet cutting machine

Dynamic 5 axis waterjet cutting machine is specially used to cut marble and granite, because it can compensate 10° cutting angle and make the stone patchwork more perfect. It is a kind of bevel cutting machines.
Due to the water jet cutting is a way of flexible cutting, therefore the product cross section will have a certain degree of inclination after cutting by the traditional 3 axis water jet cutting machine. In order to ensure the accuracy of vertical cutting section, it must reduce the cutting speed. However, our 5 axis water jet cutting machine can not only ensure the accuracy of vertical cutting section by compensating the cutting angle, but also not reduce the cutting speed.Therefore, it is the best choice to use it to cut mosaic stone, which saves the time and manpower for the second polishing of mosaic stone.

Max5 axis waterjet cutting machine

MAX5 series 5 axis water jet cutting machine unlike a conventional 3-axis waterjet cutting machine, this product is added with A-axis (in a vertical direction) and C-axis (which rotates around the Z axis).By using state-of-the-art technology and the Italian ECS control system, it can produce 0-±45° inclined cuts with a maximum rotation angle of up to ±540°. Currently, this state-of-the-art cutting equipment has been applied by a wide variety of advanced processing industries.

It can cut the product cross section without inclination, and cut bevel at any angle, as well as cut the workpiece vertically, especially cut cone, curved impeller, gear, etc.

Water Jet High Pressure Pump

Main Feature:
Control: PLC
Shifting: electro-hydraulic
Control Cooling: cooler/oil heat exchanger
Inlet water filter accuracy: ≤0.45μm
Oil-return filter accuracy: 20 μm
Working temp: 0-50°c
Outlet: UNF 3/8" Cooling in/out-let: NPT1"
Max orifice size: 0.33mm

Development

1999, YC Industry was established by Mr. Min, mainly engaged in manufacturing large production line.

2005, YC started to research and developed UHP water jet cutting equipment and cooperated with German KMT as well.

2008, YC started to cooperate with the UK agent.

2009, YC started to cooperate with USA Accustream whom is specialized in water jet parts and pumps.

2014, YC Industry built a new company Wuxi YC Waterjet Technology Co.,Ltd.

2015, YC WATERJET started to cooperate with RU agent.

2019,YC has sold the products to more than 50 countries .

Why us

We are engaged in machinery manufacturing since the year 1999,there are more than 20% workers with more than 8 years experience in water jet cutting field.

Our chief engineer Mr. Tian who started research of water jet when he was a university student has 20 years experience in water jet cutting field, and other technical persons have over 10 years experience.

YC is the partner of Accustream/Hyperthem, every year we have technical meetings with engineers from USA.

For different customers in different industries we will provide different solutions, Your water jet is tailored based on your individual needs.

Our Engineers go to many countries for installation and debugging every year.
