KIO FlowTech Top 1 flow meter manufacturer
- 100.00 piece
Registered Supplier
Direct Contact
Inquiry via Message
Product Details
| Packaging Detail: | wooden boxes; | Port: | shanghai; |
| Brand Name: | FLOWTECH; | Model Number: | KF500; |
| Place of Origin: | Zhejiang China; | Brand Name: | FLOWTECH; |
| Supply Ability: | 500 Piece/Pieces per Month; | Model Number: | KF500; |
| Type: | Variable Area Water Flowmeters,Variable Area Air & Gas Flowmeters,Variable Area Petrolum Flowmeters,Variable Area Oil Flowmeters; | Payment Terms: | L/C,T/T,Western Union; |
Turbine flow transducer adapts to measure the liquid rate and total flowrate of low viscosity,it can be widely used in the fields of petrol,chemical industry,metallurgy,scientific research for measuring or control,several putput and display methods can be selected.
1>high accuracy with 0.2%,0.5%,1%
2>wearable tungsten carbonized shaft and bearing,be the same with the medium of sully
3>erode-resistant be the same with sea water,ammonia,acetometer,etc.
4>with 4-20mA output or pulse output,LCD dispaly,totalizer
5>power supply:24VDC,or battery supply
6>explode-proffe exd II BT4/EXIBL
7>flow range is from 0.01m3/h to 800m3/h.
Specifications
| DN(MM) | Flow range(m3/h) | Medium temp.(C) | PN(Mpa) | Env. Temp.(C) | press. Loss(Mpa) | |
| Error 0.5% | Error 1.0% | |||||
| 2* | / | 0.01-0.13 | min.:-20C max.:120C | 1.6 | min.:-25 max.:55C | 0.12 |
| 3* | / | 0.04-0.25 | ||||
| 4* | / | 0.04-0.25 | 6.3 | 0.08 | ||
| 6* | 0.1-0.6 | 0.1-0.6 | 16* | |||
| 10 | 0.25-1.2 | 0.2-1.2 | 25 | 0.05 | ||
| 15 | 0.6-4 | 0.4-4 | 40* | 0.035 | ||
| 20 | 1.1-7 | 0.7-7 | 2.5 | |||
| 25 | 1.6-10 | 1-10 | 0.025 | |||
| 32 | 2.5-16 | 1.6-16 | ||||
| 40 | 3-20 | 2.5-25 | 1.6/2.5 | |||
| 50 | 4-40 | 4-40 | ||||
| 65 | 6-60 | 6-60 | ||||
| 80 | 10-100 | 10-100 | ||||
| 100 | 20-160 | 16-160 | 1.6 | |||
| 150 | 50-300 | 40-400 | ||||
| 200 | 100-600 | 80-800 |
