Manufacturer TDGC2-3 Single Phase Voltage Variac 220v Electric 5kva Variac Transformator

Product details
Delivery Detail:Shipped in 2-5 days after payment;Packaging Detail:1.Strong export package, suitable for long distance transportation 2.Standard export carton box or pallet 3.Can customized package with customer's design, carton, box, and tape;
Input voltage:220VAC;Supply Ability:50000 Piece/Pieces per Month variac with TDGC2-3KVA;
Place of Origin:Zhejiang China (Mainland);Phase:Single Phase;
Certificate:ISO9001;CE;Port:Ningbo or Shanghai;
Display:Analog Meter;Efficiency:100%;
Brand Name:Yomin Regulator;Output voltage:0~250VAC;
Current Type:AC;Output Current:12A;
Insulation Resistance:>5MΩ;Frequency:50Hz/60Hz;
Payment Terms:L/C,D/A,D/P,T/T,Western Union,MoneyGram,variac with TDGC2-3KVA;Model Number:TDGC2-3 Regulator;
Capacity:3000VA;Product Name:5kva variac;

Manufacturer TDGC2-5 Single Phase Voltage Variac 220v Electric 5kva Variac Transformator



The Voltage regulators (Variac) are used to adjust the voltage from 0 volts up to



the maximum voltage for which they have been designed and among the most



usuall applications. No additional wave from distortion. The main applications are:

  • Laboratory control equipment.
  • Lighting equipment.
  • Temperature controls.
  • Motor speed control.
  • Controlling of other transformers.
  • Etc.

Manually Operated Rotary Knob to control output voltage, by means of a control



button on the shaft of the voltage regulator (Variac) which allows to act on the



brush and achieve the desired voltage. The voltage can be smoothly varied



between turns as the brush has a relatively high resistance (compared with a



metal contact) and the actual output voltage is a function of the relative area of



brush in contact with adjacent windings.





Technical parameters



  • Capacity......................................................3000VA
  • Output Current...........................................12A
  • Output.........................................................0~250V AC
  • Frequency..................................................50/60Hz
  • Input............................................................220V AC
  • Insulation Resistance...............................>5MΩ
  • No. of Phase..............................................Single-Phase
  • Winding Material.......................................100% Copper
  • Max.Temperature......................................60℃
  • Insulation Class.........................................Class B (130℃)
  • IP/NEMA Rating..........................................IP20
  • Variable Operation....................................Manually Operated Rotary Knob
  • Portable Carrying Grip.............................Provided
  • Pollution Rating.........................................Class III
  • Analog Voltmeter Display........................Provided
  • Housing Material.......................................Shock-Proof Metal
  • Voltage Setting.........................................Manual Control
  • Standards...............................................VDE0550,IEC204-1,IEC61588,EC439
  • Sample Service........................................Pay to Provide
  • Quality Assurance...................................18Months
  • Item Condition.........................................Brand-New
ItemCapacity

Input

Voltage

Output

Voltage

Output

Current

Case

Qty.

Model(kVA)(V)(V)(A)(Pcs.)
TDGC2-0.20.22200~2500.812
TDGC2-0.50.52200~25026
TDGC2-112200~25044
TDGC2-222200~25084
TDGC2-332200~250122
TDGC2-552200~250201
TDGC2-7.57.52200~250301
TDGC2-10102200~250401
TDGC2-15152200~250601









1 Where is your factory?

Our factory is located in Qiaoqian Industry Area, Liushi Town, Yueqing City, Zhejiang Province, 325603 China.

2 Are you manufacturer or business?

We are manufacturer established in 2002, and have over 16 years production experience.

3. Can I ask for samples?

Yes

4. What's the warranty of your products?

18 months

5. What's the lead time?

Depend on the quantity and model of the order, normally it takes around 2-3 days, but the exact lead time should be discussed  with our sales.

6. How about the MOQ, Payment term, Delivery port, and shipping date?

1)MOQ: 100 pcs/item based on existing packing.

2)T/T-30% deposit and 70% against copy of BL

3)L/C is also acceptable

4)Ningbo/Shanghai
