Auto Vacuum electroplating Zinc plating machine

Supplier: Everest Pcb Equipment Co., Ltd.
Region: Beijing, China
Contact: Mr Eric Chen
Price: $50000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Available for:	small part;	Packaging Detail:	export package, wooden package, container;
Condition:	New;	Payment Terms:	L/C,T/T,SCROW;
Place of Origin:	Guangdong China;	Control system:	Full-Automatic;
Coatings:	Electro-plating;	Warranty:	1 Year;
After-sales Service Provided:	Field installation, commissioning and training,Field maintenance and repair service;	Power(W):	Customized;
Surrounding equipments:	Rectifiers Filter Tank Chiller;	Brand Name:	EVEREST;
Applicable Industries:	Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Printing Shops,Construction works ,Energy & Mining;	Supply Ability:	1 Set/Sets per Month Zinc plating machine;
Voltage:	AC220V~AC480V;	Application:	surface treatment;
Port:	Xin'gang Tianjin;	Weight:	Customer's Requested;
Dimension(LWH):	Customized;	Material:	Polypropylene(PP);

Related Products

Auto Vacuum electroplating Zinc plating machine

Zinc plating machine

Product Description

A. Process flow
Load→ Etching →Unload
B. Basic Specification
1) Overall dimension: 2110mmL*1938mmW*1878mmH
2) Work-piece dimension:

1: 600mm (Widest)
2: 150mm×150mm (Minimum)
3: 0.1-3.2mm (Thickness)
3) Conveying speed: 0-4 m/minute
4) Designed operating speed: 0.5 ~ 2.5m/minute
5) Height of conveying surface: 1050±20mm
6) Width of conveying surface: 630mm
Working width: 600mm
7) Line roller diameter: 30mm
8) Power supply: 380V/AC/50HZ/9KW
9) Throughout direction: left to right (observe from front)
10) Control system: common button control
11) Control line position: Overhead cabling
C. Comprehensive Instructions
I. Spraying System:
Etching section adopt quick disassembling cone-shape nozzles
Rinsing section adopt PVC sector shape nozzles
II. Filtration System:
Each spraying process adopts multiple filtration system which is used to protect water pump and drenching process. Especially on aspect of maintenance, our company adopts repeatable PP platy strainers which have long service life and are easy to clean.
III. Drive System and Conveying System:
1. Adopt imported variable frequency drive motor to guarantee conveying performance;
2. Main drive system: Adopt stainless steel shaft and imported PVDF bevel gear which are beautiful and wear resistant;
3. Hard roller with smooth surface to ensure conveyor stable and not scratch to substrate
4. The chemical tank adopts tilting bottom for the convenience of cleaning residual liquid;
5. The machine adopts overhead cabling which is not only safe but also beautiful;
6. Adopt overhead exhaust piping method which enables exhaust of potion sections to be adjustable regulate and control the pressure of spraying pipes.
7. The machine equiped emergency stop switch.
