GT4-14 Construction site steel straightening and cutting machine steel straightening machine wholesale

  • 800.00 set
Min. Order: 1 set FOB PRICE
Registered Supplier Direct Contact Inquiry via Message
Product Details
Packaging Detail:Standard export packing cases;After-sales Service Provided:Video technical support;
Brand Name:shuoyang;Weight:750KG;
Certification:CE;Dimension(L*W*H):1700*600*800mm;
Use:Wire;Type:Straightener & Cutter;
Port:Qingdao Tianjin Shanghai Guangdong;Place of Origin:Shandong China;
Power(W):7500;Voltage:380v;
Warranty:1 Year;Condition:New;
Supply Ability:168 Set/Sets per Week;Payment Terms:L/C,D/A,D/P,T/T,Western Union,MoneyGram;

GT4-14 Construction site steel straightening and cutting machine steel straightening machine wholesale

Sales hotline: 18905377132

Micro letter with no.

Sales: 0537-2330523

Automatic rebar straightening and cutting machine is used to straightening steel rebar, and then cut it into the needed length. It can do a prepare work for the wire mesh welding machine.So it is widely accepted to the factory who is dealing wire and wire mesh. Also widely used in construction area.

Model
GT4-14A
Straightening diameter
4-12mm
Speed of working:
40-45m/min
Error of cutting length
±5mm
Motor power
7.5kw
Overall size
1700*600*800mm

automatic used steel wire straightening and cutting machine main features
1.Use the international advanced rotary straightening structure, combined with domestic usage.All the spare parts adopt imported machining center, to guarantee the machining size, to ensure the quality of the whole machine.
2. All hydraulic components are imported from Taiwan, to overcome bad work environment and ensure that the hydraulic system can long-term operate stably.
3. All the electrical components are provided by famous brand factory.
4. Human intelligent control system, simple operation, more efficient.
5. Import terminal with shake safety, durable and waterproof.
6. All roller adopt high quality alloy steel with high hardness and good wear resistance to improve the service life.
7. The machine can realize continuous production, high efficiency, can input 99 batches at the same time.
8. Oil cylinder spring USES the German high quality import spring, spring warranty for one year.
9. The strict test run before delivery, powerful guarantee the quality of the machine.
The product is mainly applied in straightening and length cutting and applicable to cold rolling Level III Steel Bar, cold rolling plain round bar, and hot rolling coiled bar round steel. The machine is highly automatic and pulling speed is fast. It is continuous working system and is equipped with automatic counting shutdown device.
