for 24VAC 45A for EATON DILM32-10 A4 244264 XTCE032C10T CONTACTOR
-
Supplier: RST ENTERPRISE CO., LTD. -
Region: Taiwan, China -
Contact: Mr YuChi Chang -
Price: $20.00 /piece -
Min. Order: 1 piece
| Main Circuit Rating Current: | 45A; | Packaging Detail: | External Length / Height: 115 mm External Width: 55 mm External Depth: 147 mm; |
| CONTACTOR: | WHITE WITH BLACK; | Phase: | 3; |
| Place of Origin: | Romania; | Port: | Any Ports in Taiwan; |
| Number of Pole: | 3; | Supply Ability: | 120 Piece/Pieces per Month; |
| Payment Terms: | T/T,Western Union,PAYPAL; | Electricity Type: | AC; |
| Main Circuit Rating Voltage: | 24VAC; | Model Number: | DILM32-10 A4 AC24V; |
| Brand Name: | EATON; |
24VAC 45A for EATON DILM32-10 A4 AC24V XTCE032C10T 277264 CONTACTOR
Specification
- Relay Type: Contactor
- Coil Voltage VAC Nom: 24 V
- Contact Configuration: 1 N/O
- Contact Current AC Max: 45 A
- Contact Voltage AC Max: 400 V
- Mounting Type: DIN Rail / Panel
- No. of Poles: 3
- Approval Bodies: IEC/EN 60947, VDE 0660, UL, CSA
- Dielectric Voltage Coil to Contact: 440 V AC
- Dielectric Voltage Contact to Contact: 440 V AC
- IP / NEMA Rating: 00
- Insulation Voltage: 690 V AC
- Max Coil Voltage: 24 V DC
- Max Main Contact Current AC3: 45 A
- Power Rating: 15kW
Program
Product range | Contactors | ||
Application | Contactors for Motors | ||
Sub range | Complete devices up to 170 A | ||
Connection technique | Screw terminals | ||
Rated operational current | |||
AC-3 | |||
380 V 400 V | Ie | A | 32 |
AC-1 | |||
Conventional free air thermal current, 3 pole, 50 - 60 Hz | |||
Open | |||
at 40 °C | Ith =Ie | A | 45 |
Max. rating for three-phase motors, 50 - 60 Hz | |||
AC-3 | |||
220 V 230 V | P | kW | 15.5 |
380 V 400 V | P | kW | 22 |
660 V 690 V | P | kW | 30 |
AC-4 | |||
220 V 230 V | P | kW | 6 |
380 V 400 V | P | kW | 10 |
660 V 690 V | P | kW | 14 |
Approbationen | |
Product Standards | IEC/EN 60947-4-1; UL 508; CSA-C22.2 No. 14-05; CE marking |
UL File No. | E29096 |
UL CCN | NLDX |
CSA File No. | 012528 |
CSA Class No. | 2411-03, 3211-04 |
NA Certification | UL Listed, CSA certified |
Specially designed for NA | No |
Our Company
Our Prouducts
Our Service
1. Inquiry Response: Reply your inquiry in 24 working hours.
2. Delivery Time: Your shipment will be loaded in 7 ~ 30 days, depend on quantity.
3. Payment Term: T/T, Western Union, or Paypal
-
