Carbon Steel Welding Electrode E6013

Supplier: Hebei Hengshi Wire Mesh Trade Co., Ltd.
Region: Hebei, China
Contact: Mr Jade Wang
Price: $850.00 / >=5 pieces
Min. Order: 5 pieces

Click here to contact

Product details

Selling Units:	Single item;	Diameter:	2.5mm;
Welding Current:	60-90;	Standard:	AWS Standards 6013;
Operating Current:	DC AC;	Product Name:	Mild Steel Welding Electrodes E6013;
Material:	STEEL ALLOY;	Model Number:	AWS E6013;
Place of Origin:	Other-Other Country:;	Length:	300mm;
Single gross weight:	1,050 KG;	Sample:	Free;
Single volume:	1 cm;	OEM:	Accept OEM;
Inspection:	ISO, CE, SGS, BV, ABS.....;	Color:	Red, Grey, Green;
Application:	Welding low carbon steel;	Brand Name:	HENGSHI;
Package Preview:	https://sc01.alicdn.com/kf/HTB1pPU2JNSYBuNjSsphq6zGvVXau.jpg_640x640.jpg;	Trade Term:	FOB CIF CFR;
Operating Temperature:	Standard Temperature;

Welding Electrodes A 5.1 E6013

--- we supply the free sample

We hope we can get a chance to cooperate with you.

And free sample could be supplied for your inspection.

We will deal with your problems online 24 Hours available.

Product Description

AWS E6013 is a low-carbon steel electrode with a high titaniume coating and canbe used on AC. or DC . It has excellent welding technologicalproperties . The arc is stable . The spatter issmall. The slag viscosity is moderate. It can be used freely . The slag is easy to clean . The welded seam is smooth and fineand easy to restrike the arc.

Application:

Suitable for welding sheet metal structure made of low-carbon steel , such as ships,vehicles, building, and general machinery.

Chemical Composition of Wire(%):

C	Mn	Si	S	P
≤0.12	0.3-0.6	≤0.35	≤0.035	≤0.040

Mechanical Properties of Deposited Metal:

Test Item	Tensile Strength(MPa)	Yield Strength(MPa)	Elongation(%)	AKV(J)
Guarantee Value	≥420	≥330	≥17	-

Recommended Welding Current:

Electrode Diameter(Mm)	2.0	2.5	3.2	4.0	5.0
Current Range(A)	40-70	50-80	80-120	150-190	180-240

Other types of welding electrode/rod Following :

E6010 This electrode is used for all position welding using DCRP. It produces a deep penetrating weld and works well on dirty,rusted, or painted metals

E6011 This electrode has the same characteristics of the E6010, but can be used with AC and DC currents.

E6013 This electrode can be used with AC and DC currents. It produces a medium penetrating weld with a superior weld bead appearance.

E7018 This electrode is known as a low hydrogen electrode and can be used with AC or DC.

The coating on the electrode has a low moisture content that reduces the introduction of hydrogen into the weld.

The electrode can produce welds of xray quality with medium penetration.

Welding Electrode Packing Details:

SIZE(MM)	WIGHT	INNER PACKING(MM)	OUTER PACKING(MM)
2.5×300	5kg/box 4boxes/carton=20kg	3108050	320180120
2.5×350	5kg/box 4boxes/carton=20kg	3608050	370180120
3.2×350	5kg/box 4boxes/carton=20kg	3608050	370180120
4.0×400	5kg/box 4boxes/carton=20kg	4108050	420180120
inner boxes is a shrink-wrapped cardboard box. , we can do it on pallet as clients'required. 1MT/Pallet , or 2MT/Pallet.
