splitter SMATV splitter EMC121A 2-way splitter 5-2150 MHz

feature:

1. Zinc die-cast housing.

2. Unidirectional DC from all output ports to input ports: max.1A, 24V

3. Provide ground terminal

4. Full port F-(f) connector, 75Ω

5. CATV, satellite TV, MMDS low insertion loss, high return loss and isolation

6. Size: 53×46×16mm (light weight, compact size)

Frequency range (MHz)

Insertion loss(dB)

Mutual isolation (dB)

Return loss(dB)

5 - 47

≤3.5

≥21

≥10

47-863

≤3.4

≥23

≥12

863-950

≤3.6

≥22

≥11

950 - 1750

≤3.6

≥25

≥12

1750 - 2150

≤3.8

≥24

≥12

2150 - 2400

≤3.9

≥22

≥10
