New Type 2 Power Tool with Type 1 Charger Connector EV Charger Adapter Ul94 Flame Retardant 16A 32A 250V Universal
- 27.80 2 - 99 pieces
- 26.80 100 - 499 pieces
- 24.80 >=500 pieces
Registered Supplier
Direct Contact
Inquiry via Message
Product Details
| type: | J1772, Type 2, IEC62196, Type 1 | Mechanical life: | > 5000 times |
| brand: | thousands of miles | Rated current: | 32A |
| product name: | Type 2 to Type 1 EV Adapter | Operating temperature: | -30℃~+50℃ |
| Protect: | IP55 | Terminal material: | Copper alloy, silver-plated surface |
| Supply capacity: | 10000 pieces per week | port: | Shenzhen |
| payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram | Packaging Details: | Inner packing: Bubble wrapped product. Outer packing: sturdy heavy-duty carboard carton |
| Package preview: | Case material: | Thermoplastic, flammability rating UL94 V-0 | |
| Certification: | CE certification | Origin: | Guangdong, China |
| model: | EV-T2-T1 | Rated voltage: | AC 250V |
| standard: | SAE-J1772/IEC62196-2 |
Product Description
Specification
*Conform to IEC 62196-2 SAEJ1772 *Exquisite appearance, support rear installation *Contact with drainage structure, improve safety performance *Inner core: thermoplastic *Shell material: thermoplastic, flame retardant grade UL94 V-0 *Terminal material: copper alloy, Silver-plated surface *Mechanical life no-load plugging and unplugging >5000 times *Excellent protection performance, protection level up to IP67 (inside the product) *Safety pin material insulation head design to prevent employees from accidental direct contact
product name | Type 2 to Type 1 EV Adapter |
standard | IEC 62196-2, SAEJ1772-2010 |
Rated working current | 32A |
Operating Voltage | AC 250V |
Insulation resistance | >1000MQ (DC 500V) |
withstand voltage | 2000V/5 seconds |
Contact resistance | 0.5MΩ max |
Terminal temperature rise | <50K |
Operating temperature | -30℃~+50℃ |
Impact insertion force | 45N |
Mechanical life | > 5000 times |
protection level | IP55 |
Flame retardant | UL94 V-0 |
certified | CE certification |
