100 Amp 2P 4P Automatic Transfer Switch ATS Dual Power Transfer Switch

Supplier: Yueqing Yirui Electric Appliance Co., Ltd.
Region: Zhejiang, China
Price: $18.00 / >=10 pieces
Min. Order: 10 pieces

Click here to contact

Product details

Origin:	Zhejiang, China	frequency:	50Hz/60Hz
Rated voltage:	230V	Supply capacity:	50000 pieces per month
product name:	Dual Power Transfer Switch	maximum. Voltage:	230V
Warranty:	1 year	Rated current:	125A
Packaging Details:	carton	payment terms:	L/C, Western Union, D/P, D/A, T/T, MoneyGram
maximum. current:	125A	brand:	YRO
port:	Ningbo/Shanghai/Shenzhen	Certification:	International Organization for Standardization
model:	YRQ1CB-125	pole:	2p

Product Description

YRQ1CB-125 series automatic transfer switch is designed and developed by our company according to the needs of customers
Require.

The switch uses YRCB-125 (NC) miniature circuit breaker as the action element, and is equipped with a new
control mechanism.

It has the smallest volume among similar products, and it also has functions such as fire control (OPINIONAL) and power supply
generation, while it
Dedicated to important power supply places that do not allow power outages.

Specification

type	YRQ1CB-125
Specification current Ie(A)	80/100/125A
Rated working voltage, Ue (V)	AC230V/AC400V
Rated insulation voltage Ui (V)	AC 690V
Rated impulse withstand voltage (KV)	4KV
Rated short-circuit making capacity Icm	6KA
Rated short-circuit breaking capacity Icn	4.5KA
service life	5000 times
Electrical grade	CB level
controller	A type (basic type)
Rated control power supply voltage, Us(V)	230V 50/60Hz
Operation transition time (without delay)	≤3s
Key words	AC ATS automatic transfer switch
