Luckimage video conference camera conference system 1080p usb ptz meeting room camera video conference camera supplier
- 520.00 1 - 49 pieces
- 490.00 50 - 199 pieces
- 460.00 >=200 pieces
Registered Supplier
Direct Contact
Inquiry via Message
Product Details
| interface: | USB 3.0 | Video resolution: | 4k |
| sensor: | 1/2.8" CMOS sensor | Function: | remote control |
| Function: | AI Tracking | Private Mold: | Yes |
| Control interface: | RS232/RS485 | Applies to: | Video conference room/live broadcast/teaching |
| payment terms: | Wire transfer, visa | Video output: | IP+SDI+HDMI+USB |
| Origin: | Guangdong, China | Default number: | 255 |
| model: | HC510-12 | lens: | 12x optical zoom |
| brand: | lucky image | white balance: | car |
| type: | video conferencing system |
Specification
Equipment and lens parameters | ||
image sensor sensor | 1/2.8 inch high quality CMOS sensor | |
Effective Pixels | 851M, 16:9 | |
video signal | 4K30FPS | |
Lens optical magnification | 12x optical zoom | |
view | Horizontal: 6.5° (narrow angle) ~ 70.9° (wide angle) | |
Pore coefficient | F1.6～F2.8±5% | |
digital zoom | 15 times | |
Minimum illumination | 0.5Lux (F1.8, automatic gain control on) | |
digital noise reduction | 2D&3D digital noise reduction | |
white balance | Auto/manual/one-key white balance/designated color temperature | |
focus mode | Auto/manual/one key focus | |
SNR | >50dB | |
Interface function performance | ||
product port | HDMI, SDI, LAN (support POE), USB3.0, A-IN, RS232-IN, RS232-OUT, RS422 (compatible with RS485), DC12V power supply, DIP switch, switch; power switch | |
Video output interface | HDMI, SDI, LAN, USB3.0 | |
audio output interface | HDMI, SDI, LAN, USB3.0 | |
control port | RS232-IN, RS232-OUT, RS422 compatible with RS485 | |
Serial communication protocol | VISCA/Pelco-D/Pelco-P; Support 9600/4800/2400/115200/38400 baud rate | |
USB communication protocol | UVC (video communication protocol), UAC (audio communication protocol) | |
power interface | HEC3800 power socket (DC12V) | |
power adapter input | AC110V to AC220V. Output DC12V/2.5A | |
Input voltage | DC12V±10% | |
Input Current | <1A | |
Overall power consumption | ＜12W | |
AI Tracking | ||
real-time tracking | The maximum tracking distance is 6 to 7 meters, which can support the speaker to walk at a speed of 3 to 4 miles | |
area tracking | Four tracking zones can be set from -170° to +170° horizontally and -30° to +90° vertically | |
PTZ parameters | ||
horizontal rotation | -170° to +170° | |
pitch rotation | -30° to +90° | |
Default number | Users can set up to 255 preset positions (10 remote controllers) | |
Product Description
Ultra HD 4K 30FPS
Ultra-high-definition video, 4K output frame rate up to 30 frames per second, can provide extraordinary clarity and resolution of picture quality.
Multiple Interface Details
Support HDMI, SDI, USB3.0, LAN interface; support POE power supply, USB3.0 supports dual stream
Various application scenarios
Multiple scenarios and multiple application scenarios
