vacuum contactor 80A 125A 160A 250A 400A 600A 1000A 1250A 1600A 2000A 380V 1140V 3POLE CKJ5

Supplier: Yueqing Yileke Technology Co., Ltd.
Region: Zhejiang, China
Contact: Ms Anna Zhang
Price: $76.00 / 1 - 99 pieces
$75.00 / 100 - 999 pieces
$74.00 / 1000 - 9999 pieces
$73.00 / >=10000 pieces
Min. Order: 1 piece

Click here to contact

Product details

payment terms:	L/C, Western Union, T/T, MoneyGram	Packaging Details:	2PCS/carton
Number of poles:	3	Supply capacity:	1000 pieces per day
product name:	250A 1140V 3P CKJ5 AC Vacuum Contactor	stage:	three
Rated voltage:	380V	brand:	jackie
model:	CKJ5-250A	port:	Ningbo/Shanghai
Origin:	Zhejiang, China	Rated current:	250a
Package preview:		Breaking capacity:	10KA

250A 400A 1140V 3 pole CKJ5 AC vacuum contactor

Product Description

1140V 600A 3POLE CKJ5 AC Vacuum Contactor

application

CKJ5 is suitable for long-distance switching and breaking circuits in AC 50Hz, 1140V, maximum 660A power systems, and frequently starts and controls AC motors. It can also be combined with various protection devices to form an electromagnetic starter, especially suitable for the combination of explosion-proof electromagnetic starters.

Specification

type	rated current	Rated voltage	control ticket
CKJ5-80	80a	380/1140v	36/110/220/380v	36/48/110/220v
CKJ5-125	125a	380/ 1140 volts	36/110/220/380v	36/48/110/220v
CKJ5-160	160a	380/1140v	36/110/220/380v	36/48/110/220v
CKJ5-250	250a	380/1140v	36/110/220/380v	36/48/110/220v
CKJ5-400	400a	380/1140v	36/110/220/380v	36/48/110/220v
CKJ5-600	600a	380/1140v	36/110/220/380v	36/48/110/220v
