huawei OUTDOOR DC power system cabinet TP48200A-HD15A6
- 500.00 set
Registered Supplier
Direct Contact
Inquiry via Message
Product Details
| Supply capacity: | 100 sets per month | model: | TP48400A |
| port: | Shenzhen | Warranty: | 1 year |
| brand: | hardware | use: | outdoor |
| type: | Communication power | Origin: | Guangdong, China |
| payment terms: | Western Union, D/P, T/T |
contact us
Product Description
The indoor power supply system includes integrated power supply (built-in battery) and separated power supply (separated battery), with output ranging from 100A to 600A. This series can accommodate high-efficiency rectification modules, has excellent monitoring functions, and has been applied in many indoor scenarios.
Specification
integrated power supply | TP48200A-H15A3 | TP48200A-D15A1 | ||
system | Dimensions (width × depth × height) | 1500mm(H, excluding base)×650mm(W)×650mm(D) | ||
weight | 120KG | |||
Rated Capacity | 200A | 200A | ||
Alignment | Front, support modular replacement | |||
Built-in battery | not applicable | not applicable | ||
user space | not applicable | not applicable | ||
Degree of protection | IP20 | |||
AC power distribution | enter | 220V single-phase; 380V three-phase; 110V two-wire | 220V three-phase; 380V three-phase | |
Input voltage | 85~300V AC | |||
input frequency | 45~66Hz, rated: 50Hz/60Hz | |||
Input SPD | 20kA / 40kA, 8/20μs | |||
DC power distribution | The output voltage | 42~58V DC, default value: 53.5V DC | ||
Maximum output power | 12 kW | 12 kW | ||
Battery Branch | 2x125A miniature circuit breakers | 2x125A miniature circuit breakers | ||
LLVD | 2×63A, 2×32A miniature circuit breakers | 2×63A, 2×32A miniature circuit breakers | ||
avenue | 2×16A miniature circuit breaker | 2×16A miniature circuit breaker | ||
rectifier | Dimensions (width × depth × height) | 103mm×243mm×88.9mm | ||
weight | ≤2kg | |||
efficiency | >96% | |||
our service
* Stock for fast delivery
* one year warranty
* Remote technical support
* Circuit board repair
* Returns, Exchanges
* one year warranty
* Remote technical support
* Circuit board repair
* Returns, Exchanges
