Factory direct powder metallurgy sintered steel spline coupling
-
Supplier: Xiamen Pinmo New Materials Technology Co., Ltd. -
Region: Fujian, China -
Price: $0.53 / 10 - 999 pieces
$0.52 / 1000 - 4999 pieces
$0.49 / 5000 - 9999 pieces
$0.44 / >=10000 pieces -
Min. Order: 10 pieces
Product details
| Number of Teeth 1: | 9 teeth | payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram, Credit Card |
| Tip Diameter 2: | 11.17mm | Flexible or Rigid: | boring |
| Root diameter 2: | 9.9mm | Applicable industries: | Manufacturing plant, machinery repair shop, other |
| Material: | steel | Height of 9 teeth: | 11.18mm |
| Outer diameter: | 17.78 mm | Customization support: | OEM production |
| Tip Diameter 1: | 13.21 mm | Packaging Details: | plastic bag, carton |
| total height: | 29.46 mm | structure: | gear |
| brand: | jigsaw puzzle | place of origin; place of origin: | Fujian China |
| Number of Teeth 2: | 16 teeth | port: | Xiamen |
| Supply capacity: | 100000 pieces per month | Standard or non-standard: | Non-standard |
| Package preview: | Root diameter 1: | 10.41 mm | |
| Warranty: | Not applicable | Height of 16 teeth: | 10.95mm |
Product Description
| Material | copper powder; iron powder |
| Certificate | ISO9001:2008 |
| tolerant | ± 0.02-0.1mm, |
| Density range | 6-7.2/cm3 (iron) |
| surface treatment | Blackening, dacromet plating, polishing, sandblasting, electroplating, oil immersion |
| heat treatment | Ordinary quenching, carburizing, nitriding, high frequency quenching |
| application | Sports equipment, household appliances, transmission parts, vehicles, etc. |
| Performance | High precision, high wear resistance, low noise, stable and cheap |
| Processing technology | powder metallurgy sintering |
| process | Mixing - Mechanical forming - Hydroforming - Sintering - Testing strength and hardness - Auxiliary processing and surface treatment - Packaging and shipping |
| Product Details | |
| tooth number 1 | 9 teeth |
| tip diameter 1 | 13.21mm |
| root diameter 1 | 10.41 mm |
| Tooth height 1 | 11.17mm |
| mold 1 | 1.25M |
| tooth number 2 | 16 teeth |
| Tip diameter 2 | 11.17mm |
| root diameter 2 | 9.9mm |
| Tooth height 2 | 10.95 mm |
| mold 2 | 6 thousand |
| total height |
29.46 mm |
| Chamfer | 1.524mm |
| weight | 34.53 grams |
| Material | iron powder |
