Custom Development Consumer Electronics PCB PCBA Design Service 3D Drawing Industrial Design

Click here to contact

Product details

runner up:	Product one-stop service	Material:	10+
place of origin; place of origin:	Guangdong, China	MOQ:	1
Copper thickness:	1 oz	Cavity:	PROE/Solidworks/Rhino3D/CAD/UG
Supplier type:	custom	payment terms:	L/C, Western Union, D/P, D/A, T/T, MoneyGram
Types of:	home appliance pcba	design:	customer request
Supply capacity:	1,000,000 pieces per week	brand:	topwell
quality:	high quality	Features:	multifunctional
port:	Shenzhen	feature:	Sustainable
product name:	Electronic Product Design Services	color:	industrial
model:	Topwell-01

Welcome to TopwellTopwell is your single point of contact for PCB fabrication, component sourcing and one-stop PCB assembly, also offering:

our service.

- Contract Manufacturing - PCB Design and Assembly - Product Design - Prototyping - Plastics and Molds - CNC Machining - Die Casting

Product Description

*1. PCB board processing capacity:*
layers	Single side, 2 to 18 layers
Plate type	FR4, CEM-1, CEM-3, ceramic substrate, aluminum substrate, high Tg, Rogers, etc.
Composite Lamination	4 to 6 floors
biggest size	610 x 1,100 mm
Dimensional tolerance	±0.13mm
Plate thickness coverage	0.2 to 6.00 mm
Plate Thickness Tolerance	±10%
DK thickness	0.076 to 6.00 mm
Minimum Line Width	0.10mm
Minimum line spacing	0.10mm
Outer copper thickness	8.75 to 175µm
Inner layer copper thickness	17.5 to 175µm
Drilling diameter (mechanical drill)	0.25 to 6.00 mm
Finished hole diameter (mechanical drill)	0.20 to 6.00 mm
Hole diameter tolerance (mechanical drill)	0.05mm
Hole position tolerance (mechanical drill)	0.075mm
Laser drilling size	0.10mm
Plate Thickness to Aperture Ratio	10:1
Solder mask type	Green, yellow, black, purple, blue, white and red
Minimum Solder Mask	Ø0.10mm
Solder Mask Spacer Minimum Dimensions	0.05mm
Solder mask oil plug aperture	0.25 to 0.60 mm
Impedance Control Tolerance	±10%
surface finish	Hot air level, immersion gold, immersion silver, gold plating, immersion tin, gold finger

♦ The above descriptions are only for displaying the capabilities of our factory, if you have special requirements, please contact us.
