Automatic hard biscuits and Soft biscuit cookie machine Products from Shanghai Shinwei Machinery Manufacturing Co., Ltd.

Product Details

Packaging Detail:	wooden package;	Name:	automatic biscuit production machinery;
Machinery Function:	making biscuit;	Material:	Stainless Steel;
Weight:	6000kg;	Voltage:	380V;
Brand Name:	SHINWEI;	Power(W):	65kW;
Application fields:	Bakery,Snack food factory;	Port:	shanghai;
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;	Application:	Biscuit;
After-sales Service Provided:	Field installation, commissioning and training;	Warranty:	1 Year;
Supply Ability:	1 Set/Sets per Month;	Output product name:	biscuit;
Place of Origin:	shanghai;	Certification:	CE ISO9001;
Usage:	automatic biscuit production machinery;	Condition:	New;
After-sales Service Provided:	Engineers available to service machinery overseas;	Raw material:	Milk,Corn,Fruit,Wheat,Nuts,Soybean,Flour,Vegetables,Water;
Dimension(LWH):	29.6m;

Product Description

Biscuit can be grouped into hard biscuit and soft biscuit , according to the formula, process, and different forming method, Hard biscuit production line is generally composed of a feeding machine(if producing the soda biscuit or chocolate coated biscuit, another lamination process is needed), a set of dough roller, through the dough rolling and dough sheeting, then through the roller cutting machine, rest material recycling device, inlet oven machine, the entire biscuit forming line. In order to increase the biscuit types and characteristics, customers can allocate the sugar & salt sprinkling machine, egg spraying machine, calico printing machine, etc. The oven is to make the formed biscuit into delicious food. You can choose different types of bakery oven (electric/gas/diesel/thermal oil)for baking different types of products. For soft biscuit and cookie biscuit production line, only the forming machine and inlet oven machine can be the whole forming process.

Specifications

Model:	BCQ 1500
Products:	Hard Biscuit s
Width of wire mesh :	1500mm
Capacity:	1200-1600kg/h (depend on biscuit variety)
Baking oven:	66meters ;Direct heating type;gas fuel
Consumption of nature gas:	70-100M3/h
Nature gas pressure:	About 6Kpa
Temperature zone of the baking oven :	5 zones
Installation power	About 100 Kw
Manpower for running the line:	8-10persons (excludes packing section)
Factory area required:	11000085005000mm

Flour mixing----Dough sheeting----Biscuit forming----Baking----Oil spraying----Cooling----Stacking----Packing

COMPONENTS AND OTHER PARTS:

- Motor :Major equipment have adopted the motor SEW motors,other use SIEMENS.

- Inverter : Schneider.

- Touch Screen : Main Screen adopted Siemens or Schneider.

- PLC : SIEMENS

- Pneumatic components : AIR TACK

- Bearing : NSK

- Sensor/approached switch : OMRON + SICK

- Cylinder :FESTO

- Electric component : SCHNEIDER

- Ignition control : BURKERT

- PU Belt : SIEGLING

- Driving Chains : Chinese branded product.

- Temperature meter : Japanese brand, “YAMATAKE”

- Power supply : Customized

- All the material to contact with foods uses stainless steel or meets the food requirements of other materials.

Packaging & Shipping

Wooden Case

1.Product production is completed, by the quality inspection department to check

2.After inspection qualified, clean for whole machine

3.Packing:

a. Inside the machine put desiccant

b. Add 6 cm thick foam plate around the machine, Then, winding stretch film for reinforcement, and combined with bubble wrap

c. On wood packaging on the outside of the machine, then use metal reinforcement with steel

4.Container:according to different products for reinforcement

Our Services

After-sale services for all the customers

a. Free training of machine installation, operation and maintenance will be provided;
b. Some spare parts will be sent together with the machine for free and some spare parts are always at favorable price for regular customers;
c.Technical support will be offered by call, email or video etc;
d.If necessary, our engineer will go to your factory for machine installation, adjustment or maintenance
