Metal Forming Machine China Factory Forming Machine B6066 for sale
-
Supplier: Tengzhou Realgold Machinery Co., Ltd. -
Region: Shandong, China -
Contact: Mr Nicholas Wang -
Price: $1000.00 /set -
Min. Order: 1 set
| weight: | 1920 kg | Core components: | PLC, motor |
| Video shipment inspection: | if | Packaging Details: | Sea packing |
| brand: | real gold | Dimensions (L*W*H): | 2350*1225*1480mm |
| Mechanical test report: | if | port: | Qingdao or Shanghai |
| Voltage: | 380V/220V | payment terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply capacity: | 100 sets per month | After-sales service provided: | On-site service by overseas engineers, online support, video technical support, free spare parts, on-site installation and commissioning training, on-site maintenance and repair services |
| Core component warranty: | 1 year | Showroom location: | Pakistan, Thailand, Chile |
| Certification: | International Organization for Standardization | After warranty service: | Video technical support, online support, spare parts, on-site maintenance and repair services |
| Applicable industries: | Manufacturing plants, machinery repair shops | Main selling points: | competitive price |
| strength: | 3 kW | place of origin; place of origin: | Shandong China |
| Warranty: | 1 year | Function: | cutting metal |
| Health status: | new | Local service location: | Pakistan, Thailand, Kenya |
| Marketing Type: | 2019 Hot Products |
|
Specification |
unit |
BC6063/BC6066 |
BC6085 |
|
|
Maximum shaping length |
mm |
630/660 |
850 |
|
|
The maximum range of horizontal movement of the table |
mm |
385 |
400 |
|
|
The maximum distance between the bottom of the ejector rod and the table top |
mm |
630 |
710 |
|
|
The maximum length of the table moving up and down |
mm |
360 |
360 |
|
|
Table size(L*W) |
mm |
630X400/660X400 |
800X450 |
|
|
Head travel |
mm |
120 |
160 |
|
|
Stamping strokes per minute |
next minute |
14,20,28,40,56,80 |
17,24,35,50,70,100 |
|
|
tool head rotation |
° |
+/-60 |
+/-60 |
|
|
Maximum size of handle (W*T) |
mm |
20X30 |
- |
|
|
Table feed range |
Level 12 steps |
mm |
0.4-5 |
0.25-3 |
|
12 vertical steps |
mm |
0.08-1.00 |
0.12-1.5 |
|
|
Centering T-slot width |
mm |
18 |
twenty two |
|
|
main motor power |
kilowatt |
3 |
5.5 |
|
|
Dimensions (L*W*H) |
mm |
2000X1300X1550/2357X1225X1480 |
2950X1325X1693 |
|
|
Net weight/Gross weight |
Kilogram |
1750/1870 1800/1920 |
2040/3090 |
|
Feedback within 18 hours is our commitment
REALGOLD Overview:
♦ 97% customer retention rate
♦ 10,000+ cooperative customers
♦ 25 years of brand operation, 15 years of machine tool building
♦100% focus on the best interests of our clients
181 month warranty,
Confidence in our quality and peace of mind for our customers.
We will provide parts or repair services free of charge within 18 months of the bill of lading date. Extended warranty available with purchase.
-
