Factory Price FOIF LP402L Theodolite Total Station Model

Click here to contact

Product details

LCD display backlight:	Yes	Warranty:	1 year, 1 year
Supply capacity:	400 pieces per month	brand:	discretionary investment fund
payment terms:	Western Union, T/T, Credit Card	Laser spot size:	5mm/100m
field of view:	1°30'	Waterproof and dustproof:	IP55
model:	LP402L	enlarge:	30 times
accuracy:	2''	port:	Shanghai
place of origin; place of origin:	Jiangsu, China	Packaging Details:	Standard packing including suitcase and carton
Customization support:	OEM production

Product Description


telescope
length	149 mm (5.9 inches)
Objective lens aperture	45 mm (1.8 inches)
enlarge	30 times
Resolution	2.5''
image/field of view	Upright/1°30'(26m/1,000m)
minimum focus	0.9 m (3.0 ft)
stadium	Multiplication constant: 100, Addition constant: 0
Marking lighting	Yes
angle measurement
method	Absolute Rotary Encoder Scanning
display resolution	1''/5'' 0.2/1mgon
accuracy	2''
Circle diameter	71 mm (2.8 inches)
Automatic Compensation Range	±3'(±55mgon)
General
Control Panel Layout	double sided
exhibit	LCD, 7 digits x 2 lines, backlight
interface	RS-232C
Optical plummet	Magnification: 3x, field of view: 3°, minimum focus distance: 0.5m (1.64ft)
Dustproof and waterproof	IP66
power supply
Battery	LR6/AA batteries x 4
Working hours (theodolite only)	about 100 hours
