FTTB CATV Booster

Supplier: Ningbo Youxin Optic-Electronic Technology Co., Ltd.
Region: Zhejiang, China
Contact: Ms helenda sun
Price: $10.00 /piece
Min. Order: 1 piece

Click here to contact

Product details

Maximum output level:	105dBμV	power supply:	220V~ 50-60Hz
aspect:	135x78x38mm	In-band flatness:	±0.5dB
Nominal gain:	30±2dB	Supply capacity:	10000 pieces per month
brand:	Tomoshin	Packaging Details:	Export cartons as standard
Nominal Input Level:	72dBμV	place of origin; place of origin:	Zhejiang, China
payment terms:	L/C,T/T,Western Union	Return Loss:	≥9dB
Frequency Range:	45~860MHz	Certification:	ce
model:	APF2000	port:	Shanghai

details

Indoor CATV Amplifier with Chinese Amplifier Module, Forward Path, 2 Output Ports, 45-862MHz, Gain 30dB, Variable EQ (18dB) and ATT (15dB), 102dBuV, Imperial F Female, AC160~250V (Power Cord With flat European plug (2 poles) or 30~60V.

feature:

(1) Chinese power amplifier module

(2) High gain, high output level, low nonlinearity

(3) Forward path variable attenuator (0~15dB) and equalizer (0~18dB)

(4) 2 outputs with plug-in splitter or 1 tap

(5) Customers specify different frequency divisions

(6) Local and remote power supply available

(7) Weatherproof and RF shielded die-cast housing

scope

thing	Specification
forward path
Frequency Range	47/87-862 MHz
get	30±1.0dB
Flatness	± 1.0 dB
Gain adjustment	0~15dB
slope adjustment	0~18dB
Rated input level	72 dB
Rated output level	102 dB
Noise Figure	≤10dB
C/CTB	≥58dB
C/CSO	≥56dB
group delay	≤10ns (112.25MHz/116.68MHz)
Hum mode.	<2%
return loss	≥14dB
impedance	75Ω
Remote/local power	AC15~60 / AC165~250 V
energy consumption	8 VA
surge protection	>5 kV
Operating temperature	-20~+50℃
aspect	178x100x55 mm
