VRF system R410A DC central air conditioner

Supplier: Shandong Rivast Air Conditioning Co., Ltd.
Region: Shandong, China
Contact: Ms Yolanda Wang
Price: $139.00 /set
Min. Order: 1 set

Click here to contact

Product details

Operating Voltage:	220V	Certification:	CE, CE
brand:	Xinjiang Han	Video external inspection:	if
Local service location:	not any	Main selling point:	easy to operate
Supply capacity:	30 sets per day	port:	Tianjin Port or Qingdao Port
Packaging Details:	VRF System R410A DC central air conditioner	payment terms:	L/C,T/T,Alibaba Trade Assurance
Fan Type:	ceiling cassette	place of origin; place of origin:	Shandong China
Health status:	new	Install:	ceiling mount
Heating capacity:	2700~18900W	Mechanical test report:	if
Core components:	motor	Applicable industries:	Hotels, Clothing Stores, Building Materials Stores, Mechanical Repair Stores, Manufacturing Plants, Food and Beverage Plants, Farms, Restaurants, Home Use, Retail, Food Stores, Printing Stores, Construction Works, Energy and Mining, Food and Beverage Stores, Advertising Agencies
Cooling capacity:	1800~12600W	Core Components Warranty:	1 year
Packaging Preview:		manufacturer:	China
After-sales service provided:	Online support	Marketing Type:	New Products 2020
Showroom location:	not any	product name:	Cassette fan coil unit
application:	restaurants, hospitals, hotels, etc.	Material:	Galvanized steel
Warranty:	1 year	type:	fan coil unit
Card:	Xinjiang Han	color:	white
air flow:	2380	After Warranty Service:	Video technical support, online support

VRF System R410A DC central air conditioner

Product Description

What is VRF?

Compared to other HVAC systems available, the VRF system is one of the most advanced and energy efficient air conditioning systems. VRF systems have four defining characteristics.

1. First, these systems use only refrigerant to generate cool air. Compare this to a traditional HVAC system that uses water to cool the air. In traditional systems, the refrigerant is used only to cool the water, which is then circulated through the system.

2. Secondly, the VRF system uses an inverter compressor. These low-energy compressors have very limited power consumption and only allow the equipment to extract enough energy to perform partial cooling of the system.

3. Second, VRF systems have multiple air handlers that can be linked together in the same refrigerant circuit.

4. Finally, this defining feature enables the VRF system to be modularly scalable for growing projects.

The fan coil unit is mainly composed of a centrifugal fan and a coil heat exchanger. It is the terminal equipment of the central air-conditioning system. The fan sends indoor air or outdoor mixed air into the room for cooling or heating through the air cooler, and then lowers or raises the indoor temperature to meet people's comfort requirements.

Models and Performance			FP-34	FP-51	FP-68	FP-85	FP-102	FP-136	FP-170	FP-204	FP-238
Rated air volume m3/h		High	340	510	680	850	1020	1360	1700	2040	2380
		Moderate	260	390	510	640	770	1020	1280	1530	1790
		low	170	260	340	430	510	680	850	1020	1190
Rated cooling capacity KW		H	1.98	2.8	3.87	4.58	5.42	7.38	9.08	11.1	12.9
Rated cooling capacity KW		H	1702	2408	3328	3938	4661	6346	7808	9546	11094
Rated heat KW		H	3.39	4.5	6.35	7.45	9.22	12.4	16.3	19.5	20.2
Rated heat KW		H	2915	3870	5460	6407	7930	10665	14020	16770	17370
Input power W	12Pa	H	37	52	62	76	96	134	152	189	228
	30Pa	H	44	59	72	87	108	156	174	212	253
	50Pa	H	49	66	84	100	118	174	210	250	300
Noise decibel (A)	12Pa	H	37	39	41	43	45	46	48	50	52
	30Pa	H	40	42	44	46	47	48	50	52	54
	50Pa	H	42	44	46	47	49	50	52	54	56
Water flow Kg/h			350	510	660	800	980	1280	1600	1920	2230
Water resistance Kpa			30	30	30	30	40	40	40	40	50
power supply			220V/50Hz
