Productivity 130m3/h 38m concrete pump trucks for sale
- 16000.00 1 - 4 units
- 15500.00 5 - 999 units
- 15000.00 >=1000 units
Registered Supplier
Direct Contact
Inquiry via Message
Product Details
| Video external inspection: | if | Marketing Type: | normal product |
| Packaging Details: | Transport trailers - naked, waxed, shipped by bulk carrier or container depending on size. Transportation====100% Convenient and efficient! concrete pump truck | Core components: | Pressure Vessels, Motors, Bearings, Gears, Pumps, Gearboxes, Engines, PLCs |
| Health status: | new | Unique Selling Points: | High operating efficiency |
| Mechanical test report: | if | payment terms: | L/C,D/P,D/A,T/T |
| Radius of gyration: | 36.5m | place of origin; place of origin: | Shanghai |
| weight: | 24500 kg | product name: | concrete pump truck |
| Reach depth: | 28m | maximum. Horizontal conveying distance: | 36.5m |
| Supply capacity: | 1000 units per week | Warranty: | 1 year |
| engine: | WD615.96, 279kw | Theoretical output: | 130 cubic meters/hour |
| productivity: | 100 cubic meters/hour | Applicable industries: | Manufacturing, Construction, Energy & Mining |
| Showroom location: | not any | maximum. Vertical conveying distance: | 38m |
| brand: | Chinese brand | port: | China's main ports |
| Arrival altitude: | 38m | Concrete pumping pressure: | 8Mpa |
| Gross weight: | 24500 kg | Rotation angle: | ±270. |
| Dimensions (L*W*H): | 12000*2500*3900mm | Core Components Warranty: | 1 year |
| Packaging Preview: | chassis: | ZZ5307N4647C | |
| Power Type: | diesel engine |
Product Description
Specification
describe | unit | parameter value | |||
Dimensions | mm | 12000×2500×3900 | |||
gross weight | Kilogram | 24500 | |||
chassis | Model | ZZ5307N4647C | |||
maximum. speed | km/h | 90 | |||
maximum. level ability | % | 40 | |||
wheelbase | mm | 4600+1350 | |||
fetal | 11.00R22.5 | ||||
engine | Model | WD615.96 | |||
maximum. strength | kilowatt | 279 | |||
maximum. torque | N m/(r/min) | 1590/1100~1600 | |||
shift | large | 9.276 | |||
Emission Standards | Erro III | ||||
pumping system | theoretical output | m3/hour | 130 | ||
concrete pumping pressure | MPa | 8 | |||
Theoretical pumping time | time/minute | 24~27 | |||
Conveying cylinder diameter × stroke | mm | φ230×2000 | |||
maximum. pumped concrete diameter | mm | 40 | |||
fill height | mm | 1580 | |||
Concrete slump range | centimeter | 8~23 | |||
place arm | reach altitude | Meter | 38 | ||
reach depth | Meter | 28 | |||
radius of gyration | Meter | 36.5 | |||
Slewing angle | ° | ±270 | |||
The first expansion angle | ° | 90 | |||
Section 2 Expanding Angle | ° | 180 | |||
The third section unfolds the angle | ° | 245 | |||
Section 4 Expanding Angle | ° | 235 | |||
Stabilizer span | Stabilizer Longitudinal Span | mm | 6421 | ||
Front stabilizer lateral span | mm | 5430 | |||
Lateral span of rear stabilizer | mm | 7381 | |||
other | Lubrication method | automatic lubrication | |||
control method | Manual/remote control | ||||
Tank volume | large | 600 | |||
Ingredient Type | skirt valve | ||||
Lubrication method | automatic lubrication | ||||
control method | Manual/remote control | ||||
Tank volume | large | 400 | |||
water pump pressure | MPa | 2 | |||
