Lead Coil 2V025-08 2Port 2Pos 1/4" BSP Normally Closed Solenoid Valve

Supplier: Ningbo Epsolid Pneumatic Components Co., Limited
Region: Zhejiang, China
Contact: Mr EPSolid Zhuo
Price: $5.00 / 1 - 9 pieces
$3.40 / 10 - 99 pieces
$3.20 / 100 - 499 pieces
$3.00 / >=500 pieces
Min. Order: 1 piece

Click here to contact

Product details

place of origin; place of origin:	Zhejiang, China	strength:	electromagnet
Single package size:	5X5X2 cm	application:	general
type:	Air and Vacuum Release Valves, Solenoid Valves	structure:	control
Custom Support:	OEM, ODM	Standard or non-standard:	standard
Gross weight per piece:	0.200 kg	brand:	EPSolid
Packaging Preview:		Coil:	wire
Sales unit:	single product	color:	black and silver
Medium temperature:	medium temperature	model:	2V025-08
Body material:	alloy	voltage:	12~240V AC/DC
Packaging Details:	Box	Port size:	1/8'' or 1/4'',1/4''
Sealing material:	Nitrile or Viton	media:	according to

Product Description

The title is here.

Model 2V025-06 2V025-08

Working medium air, water, oil, gas

Action mode Direct drive type

Type normally closed

Aperture flow 2.5mm

CV value 0.23

Port size G1/8''(NPT) G1/4''(NPT)

Working fluid viscosity 20CST (below)

Working pressure 0~0.7Mpa

maximum. Pressure 1.0Mpa

Operating temperature range -5~+80'C

Voltage range 10% up and down

Body alloy material

Oil seal material NBR or FKM

detailed image
