BSM100GD120DN2 IGBT Power Module (Solderable Power module 3-phase full-bridge Including fast free-wheel diodes)

Supplier: Shenzhen Kinger Henly Technology Co., Ltd.
Region: Guangdong, China
Contact: Ms Elisa Lin
Price: $1.00 /piece
Min. Order: 1 piece

Click here to contact

Product details

Product Name:	IGBT Power Module;	IC:	150A;
Weight:	300G;	VCE:	1200V;
Type:	Other;	Ptot:	680W;
Size:	121.561.520.5mm;	Brand Name:	Original Brand;
Shipping by:	DHL,UPS,Fedex and EMS;	Packaging:	Factory Sealed Packing;
Delivery Time:	In stock;	Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;
Package Type:	Other;	Type:	3 Phase Full-Bridge;
Model Number:	BSM100GD120DN2;	Place of Origin:	Japan;

Product Description

BSM100GD120DN2

IGBT Power Module

* Solderable Power Module

* 3-phase full-bridge

* Including fast free-wheel diodes

* Package with insulated metal base plate

Parameter	Symbol	Values	Units
Collector - emitter voltage	VCE	1200	V
Collector - gate voltage , RGE =20 kΩ	VCGR	1200	V
Gate - emitter voltage	VGE	± 20	V
DC collector current , Tc =25 °C Tc=80 °C	IC IC	150 100	A A
Pulsed collector current , tp=1ms, Tc=25 °C Tc=80 °C	ICpuls ICpuls	300 200	A A
Power dissipation per IGBT , Tc=25 °C	Ptot	680	W
Chip temperature Storage temperature	Tj Tstg	+150 -55 to +150	°C °C
Thermal resistance , chip case Diode thermal resistance , chip case	RthJC RthJCD	≤ 0.182 ≤0.36	K/W K/W
Insulation test voltage , t=1min.	Vis	2500	Vac
Creepage distance Clearance		16 11	mm mm
