Chinese 63m Truck Mounted Concrete Pump 63X-6RZ With Boom
-
Supplier: Acntruck Automobile Sales (Shanghai) Co., Ltd. -
Region: Shanghai, China -
Contact: Ms Willow Shen -
Price: $22000.00 / 1 - 1 units
$18000.00 / >=2 units -
Min. Order: 1 unit
Product details
| Theoretical output: | 200m3/h; | Core Components: | Engine; |
| Warranty: | 1 Year; | Reach height: | 60m; |
| Concrete slump range: | 8~23cm; | Packaging Detail: | Nude or by container.; |
| Applicable Industries: | Hotels,Garment Shops,Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Food & Beverage Factory,Farms,Restaurant,Home Use,Retail,Food Shop,Printing Shops,Construction works ,Energy & Mining,Food & Beverage Shops,Advertising Company; | Showroom Location: | None; |
| Marketing Type: | New Product 2020; | Max. Concrete Pressure: | 83/120 bar; |
| Port: | Shanghai,Qingdao,Lianyungang,Tianjin; | UNIQUE SELLING POINT: | Long lifetime; |
| Condition: | New; | Filling height: | 1540 m; |
| After-sales Service Provided: | Video technical support,Field installation, commissioning and training,Field maintenance and repair service,Free spare parts,Online support; | Power Type: | Diesel; |
| Theoretical pumping times: | 24~27min; | Wheelbase: | 4600+1350mm; |
| Productivity: | 200M3/H; | Machinery Test Report: | Provided; |
| Supply Ability: | 100 Unit/Units per Week; | Payment Terms: | L/C,Western Union,D/P,D/A,T/T,MoneyGram; |
| After Warranty Service: | Video technical support,Spare parts,Field maintenance and repair service; | Dimension(L*W*H): | 9900*2525*3750mm; |
| Package Preview: | ; | Max. horizontal conveying distance: | 160M; |
| Max. speed: | 90km/h; | Warranty of core components: | 1 Year; |
| Local Service Location: | None; | Max. vertical conveying distance: | 120M; |
| Emission standard: | Eruo III; | Certification: | CE/ISO9001; |
| Place of Origin: | Hunan, China; | Product name: | Concrete Pump Truck 60m; |
| Weight: | 24500kg; | Video outgoing-inspection: | Provided; |
| Brand Name: | ZOOMLION; |
Acntruck
200m3/h concrete mixer truck with pump semi-trailer 60m
Selling Point:
- • Compact in design, 60m pump mounted on 5-axle truck.
• Efficient pump unit, two Rexroth main pumps gives a big output, easy to use and maintenance.
• Agile placing boom with 6 arms with unfolding height 14m only, which gives a wide work range.
• One side lateral support enables to work in narrow sites.
• Controller is designed for heavy duty use, with a monitor, it monitors the pump intelligently on working data management, real-time diagnostics, alarm logging, and service interval notice.
• Rich in configurations and high quality components
|
Distribution valve |
S-valve |
|
|---|---|---|
|
Max. Concrete Output |
m3/h |
200/140 |
|
Max. Concrete Pressure |
bar |
83/120 |
|
Delivery Cylinder |
mm |
260 |
|
Stroke Length |
mm |
2100 |
|
Strokes |
1/min |
30/21 |
|
Hopper Capacity |
L |
600 |
|
Filling height |
mm |
1540 |
|
Hydraulic System |
Closed |
|
|
Hydraulic oil cooling |
Double fans |
|
|
High/Low Press. Switch |
Manual |
|
|
Lubrication on pump |
Automatic |
|
|
Lubrication on hopper |
Automatic |
|
|
GPS Data Manage |
Optional |
|
|
Boom Control Valve |
Proportional |
|
|
Number of Arms |
|
6 |
|
Folding System |
|
RZ |
|
Max. Reach Vertical |
m |
60 |
|
Max. Reach Horizontal |
m |
55 |
|
Max. Reach Depth |
m |
43.6 |
|
Min. Unfolding Height |
m |
14 |
|
End Hose Length |
m |
3 |
|
Pipeline |
DN125/5.5 |
|
|
Slewing Range |
±270° |
|
|
Slewing Motors |
2 motors |
|
|
Remote Control System |
Radio |
|
|
Water Pump |
20L/min, 60bar |
|
|
Tool kits with box |
Standard |
|
