All In One Portable MIG Welders IGBT Inverter TRIX-200 amp with Gas and Gasless

Supplier: Taizhou Lemin Welding Equipment Co., Ltd.
Region: Zhejiang, China
Contact: Mr Jack Ye
Price: $205.00 / 1 - 99 pieces
$185.00 / 100 - 299 pieces
$170.00 / >=300 pieces
Min. Order: 1 piece

Click here to contact

Product details

Place of Origin:	China;	Model Number:	MIG-200 TRIX;
Use:	Industrial;	Phase:	230V;
Packaging Detail:	Welding Machine Mig Welder Carbon Max Duty Metal Steel Training Power Technical Parts Dimensions packed in a honeycomb box;	No-load Voltage:	60V;
Package Preview:	;	Brand Name:	FENGBAO;
Spare parts:	Electrode Holder;	Frequency:	50/60Hz;
Max Material Thickness:	1.0mm;	Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;
Functions:	MIG MAG;	Port:	NingBo;
Duty cycle:	30%;	Weight:	19KG;
Supply Ability:	5000 Piece/Pieces per Month;	MIG Current Range:	20-200A;
Min Material Thickness:	0.6mm;	Max Wire Diameter:	1.0mm;
TIG Current Range:	10-180A;	Dimension (L x W x H):	600300460mm;
MMA Current Range:	20-180A;

Products Description

Details Images

Product Paramenters

Product Model:	MIG-200 TRIX
Product Description:	IGBT INVERTER MIG-MAG/FLUX/TIG/MMA INVERTER WELDING MACHINE
Rated Input Voltage:	1phase, 230V +/- 15%
Rated input Power:	7.5Kw
Frequency:	50/60Hz
No-load Voltage:	60V
Rated Duty Cycle:	40%
Effenciency:	85%
Class of Insulation:	F
Protection Level:	IP21
Power Plug:	20A
Output Current:	MIG/MAG/FLUX	20-200A
		MMA/ARC/STICK	20-180A
		TIG/ LIFT TIG	20- 180A
Function Support:	HOT START	Available
		ANTI STICK	Available
		ARC FORCE	Available
		FLUX WELDING	Available
		PULSE WELDING	NOT Available
Size & Weight:	Product Dimension	570x280x450mm
		Poduct Weight	14Kg
		Package Dimension	640x380x450mm
		Package Weight	18Kg
Accessories:	Standard Accessories：	- 1x MB15AK MIG TROCH with 3m cable
				- 1x 200A Electrode Holder with 2m cable
				- 1x 300A Ground Clamp with 2m cable
				- 1x Welding mask
				- 1x Chipping Hammer/Brush
				- 1x Manul Book
		Optional Accessories：	- WP17V LIFT TIG Torch with 4m cable.
		Optional Accessories：		- Storage Box
	* NOTE: the optional accessories is required extra cost, if you need them, please inquiry factory before placing order *

Certifications

After-sales Services

Do you have any concerns about the after-sales service of the machines you buy?

We have a complete set of after-sales service system to ensure that you have no worries about purchasing. 1. We provide quality assurance service for up to 12 months wanrranty. The effective time of service is calculated form the date of purchase or Boarding date of BL. 2. For each order, we will provide 1% free PCB or key components for your maintenance. 3. If you encounter problems which can't be fixed by yourself, we can provide technical support through video communication. 4. If bad quality problems occur, our salesmen and technicians will personally go to your company to inspect and repair, and offer solutions.

Company Profile

OUR MANUFACTURER

TAIZHOU LEMIN WELDING EQUIPMENT CO., LTD is the manufacturer of DECAPOWER company group.

We're focusing on developing and producing reliable quality Inverter Welding Machines and Air Plasma Cutter with favorable price, such as MMA/ARC WELDER, TIG WELDER, MIG WELDER and AIR PLASMA CUTTER which has been approved by CSA, CCC, CE certificate.

CORE TARGET:

Tailor client's assortment products with innovation, competitive price and well presentation.

PEOPLE:

We're culturally diverse globally gained. Our Knowledge and Industry focused terms are driven to satify and exceed customer's expectations.

CULTURE:

Our "CAN-DO" and "YES.WHY NOT" philosophy defines DECAPOWER's global approach. Our customer-centric spirit makes it easy to work and being partner with us.
